BOE GT080S0M-N11-1QP0 Mechanical Details
Pixel Features :
Number of Pixel
800(RGB)×600, SVGA
Arrangement
RGB Vertical Stripe
Dot Pitch(W×H)
0.0675×0.2025 mm
Pixel Pitch(W×H)
0.2025×0.2025 mm [125PPI]
Physical Size :
Active Viewing
162(W)×121.5(H) mm
Overall Dim.
183(W)×141(H) mm
Bezel Opening
164.8(W)×124.3(H) mm
Overall Depth
5.6±0.3 mm
Outline Features :
Form Shape
Flat Rectangle
Orientation
Landscape type
Aspect Ratio(W:H)
4:3
Shape Style
BOE GT080S0M-N11-1QP0 Optical Details
Basic Information :
Luminance
250 cd/m² (Typ.)
Contrast Ratio
500:1 (Typ.) (Transmissive)
Good View at
12 o'clock
Response Speed
20 (Typ.)(Tr+Td) ms
Viewing Angle
75/75/75/70 (Typ.)(CR≥10)
Operating Mode
TN, Normally White, Transmissive
Color Performance :
Chromaticity
Wx:0.310; Wy:0.310
Support Color
262K/16.7M (6-bit / 6-bit + Dithering)
Color Temperature
6852K
White Variation
-
BOE GT080S0M-N11-1QP0 Interface Details
Signal Electrical :
Input Current
120/30.5/0.5/4.21mA (Typ.)(IDD/AIDD/IGH/IGL)
Input Voltage
3.3/10/21/-7.78V (Typ.)(VDD/AVDD/VGH/VGL)
Consumption
-
Signal Interface
Parallel RGB (1 ch, 6/8-bit)
Interface Features :
Position
-
Physical Type
FPC
Interface Detail :
Brand
Model
Pin Pitch
Pins
Amount
Pin Assignment
0.5 mm
50 pins
1 pcs
DRGB-50P1C8B-115A
whose pixels are arranged in RGB Vertical Stripe. As for mechanical
detail, it features active area of 162(W)×121.5(H) mm, outline size
of 183(W)×141(H)×5.9(D) mm, viewing area size of 164.8(W)×124.3(H)
mm, with surface treament of Antiglare. As a TN, Normally White,
Transmissive LCM product, GT080S0M-N11-1QP0 can provides 250 cd/m²
display brightness 500:1 transimissive contrast ratio, 75/75/75/75
(Typ.)(CR≥10) (L/R/U/D) viewing angle , and response time of 20
(Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is
determined with a 6-bit / 6-bit + Dithering gray scale signal for
each dot, thus presenting a palette of 262K/16.7M colors, also with
performance of color gamut 50% (NTSC). This product adopted 4S5P
WLED as it's backlight systerm which was placed as Edge light type,
external backlight driver is additionally needed. GT080S0M-N11-1QP0
utilizes Parallel RGB (1 ch, 6/8-bit) as it's signal inputting
systerm, which connected by 50 pins FPC with power supply voltage
of 3.3/10/21/-7.78V (Typ.)(VDD/AVDD/VGH/VGL). It's typical vertical
frame rate (Fv) is 60Hz.
According to datasheet with version of Rev.1 which was released out
on 2 27 2021, GT080S0M-N11-1QP0 supports display 800(RGB)×600 (SVGA) with aspect ratio of 4:3 (W:H), whose pixels are arranged in
RGB Vertical Stripe. As for mechanical detail, it features active
area of 162(W)×121.5(H) mm, outline size of 183(W)×141(H)×5.9(D)
mm, viewing area size of 164.8(W)×124.3(H) mm, with surface
treament of Antiglare. As a TN, Normally White, Transmissive LCM
product, GT080S0M-N11-1QP0 can provides 250 cd/m² display
brightness 500:1 transimissive contrast ratio, 75/75/75/70
(Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on 12
o'clock , and response time of 20 (Typ.)(Tr+Td) ms. Gray scale or
the brightness of the sub-pixel is determined with a 6-bit / 6-bit
+ Dithering gray scale signal for each dot, thus presenting a
palette of 262K/16.7M colors, also with performance of color gamut
50% (NTSC). This product adopted 4S5P WLED as it's backlight
systerm which was placed as Edge light type, external backlight
driver is additionally needed. GT080S0M-N11-1QP0 utilizes Parallel
RGB (1 ch, 6/8-bit) as it's signal inputting systerm, which
connected by 50 pins FPC with power supply voltage of
3.3/10/21/-7.78V (Typ.)(VDD/AVDD/VGH/VGL). It's typical vertical
frame rate (Fv) is 60Hz. For more latest product detail of
GT080S0M-N11-1QP0 We strongly recommend that you should refer to
datasheet listed on Panelook.com or contact with BOE or it's
distributor. All specification details are inputted by Panelook
engineers according to datasheet, but we cannot guarantee the spec
listed is entirely correct.
