    High Power DIP Varistor 34S112K 32D 25D 40S 40D 53D 20D 14D 10D 7D 5D 391K 431K 471K 511K 561K 621K For SPD Surge Protec

    Ask Lasest Price
    Brand Name : CNAMPFORT
    Model Number : MYL34S-112
    Certification : ROHS,UL,CE
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 10KKPCS PER MONTH
    Delivery Time : 2-3 Weeks
    • Product Details
    • Company Profile

    High Power DIP Varistor 34S112K 32D 25D 40S 40D 53D 20D 14D 10D 7D 5D 391K 431K 471K 511K 561K 621K For SPD Surge Protec

    High Power DIP Varistor 34S112K 32D 25D 40S 40D 53D 20D 14D 10D 7D 5D 391K 431K 471K 511K 561K 621K For SPD Surge Protection

    Varistors are used to protect a circuit from high voltage surges. When a high voltage surge is applied to a circuit, the outcome is usually catastrophic to the circuit. A capacitor may be installed across the signal lines. However, this capacitor cannot suppress voltage surges.

    Wide operating voltage (V1mA) range from 82V to 1600V

    Fast responding to transient over-voltage

    Large absorbing transient energy capability

    Low clamping ratio and no follow-on current

    Meets MSL level 1, per J-STD-020

    Operating Temperature:-40℃ ~ +85℃

    Storage Temperature:-40℃ ~ +125℃

    Transistor, diode, IC, thyristor or triac semiconductor protection

    Surge protection in consumer electronics

    Surge protection in industrial electronics

    Surge protection in electronic home appliances, gas and petroleum appliances

    Relay and electromagnetic valve surge absorption

    ITEM NO.MAXIMUN RATING(85℃)SPECIFICATION(25℃)
    Continuous VoltageEnergyPeak Current (8/20μs)Varistor Voltage(lmA DC)@Ip Clamping VoltageTypical Capacitance
    VRMSVDCWTM(J)
    VM(AC)(V)VM(DC)(V)(10/1000μs)Imax(kA)Min(V)VN(DC)(V)Max(V)Vc(V)Ip(A)F=1KHz(pF)
    34S-201130175310401842002243403007900
    34S-221140180330401982202423603007200
    34S-241150200360402162402593953006600
    34S-271180230390402552703004553005600
    34S-331210270430402973303635503005000
    34S-361230300460403263603965953004400
    34S-391250330490403543904296503004100
    34S-431275360550403894304667103003800
    34S-471300390600404254705177903003400
    34S-511320420640404625105588503003200
    34S-561360470710405225606259503002900
    34S-6213905058004055862067410253002600
    34S-6814205609104061268073611203002400
    34S-7514606159204067575081512403002200
    34S-7814806409304070278085813003002100
    34S-8215106759404073882088813503002000
    34S-9115507009604081991093314003001800
    34S-95158073510004085595098815003001700
    34S-1026208001040409001000108016503001600
    34S-1126808601100409901100118018003001500
    34S-12275097012004010801200132020003001300
    34S-142880115013004012601400152022003001100
    34S-1621000120014004014401600168825503001000
