    GV 70 Backstop Clutch One Direction Cam Clutch Roller Bearing GV Series Overrunning Clutch

    Ask Lasest Price
    Brand Name : Tianniu
    Model Number : GV series
    Certification : ISO9001
    Price : Negotiable
    Payment Terms : T/T, Western Union, MoneyGram, L/C, D/A, D/P
    Supply Ability : 10000 per month
    Delivery Time : 10-15 working days
    MOQ : 1 Piece
    • Product Details
    • Company Profile

    GV 70 Backstop Clutch One Direction Cam Clutch Roller Bearing GV Series Overrunning Clutch

    GV 70 Backstop Clutch One Direction Cam Clutch Roller Bearing GV Series Overrunning Clutch

    Product Description

    GV 40 Backstop Clutch One Direction Cam Clutch Roller Bearing

    Features

    Type GV is a roller type freewheel. It is self-contained, centered by plain bearings for low rotational speeds, and sealed using shield protected metallic labyrinth seals.. Unit is delivered grease lubricated, ready to install in a horizontal or vertical position. Primarily used as a backstop, the torque capacity is high for a minimum space requirement.

    This design is suitable for use in difficult environments. A bolt, secured to a fixed part of the machine and passing through the slot in the torque arm, provides the rotational stop. Radial clearance on this bolt should be equal to 1–3 % of the slot width.The torque arm and the bearings must not be prestressed. The roller design makes the

    GV type ideal for light indexing applications.

    Dimension and Capacity

    GV 40 Backstop Clutch One Direction Cam Clutch Roller Bearing

    Model

    dH7

    mm

    D

    mm

    L

    mm

    B1

    mm

    L1

    mm

    b2

    mm

    I2

    mm

    I3

    mm

    I4

    mm

    Weight

    Kg

    Max Speed

    Torque

    Nm

    Drag Torque Nm
    GV20 20 83 35 40 12 15 35 5 90 1.3 450 275 0.2
    GV25 25 83 35 40 12 15 35 5 90 1.3 450 275 0.2
    GV30 30 118 54 40 15 15 35 8 110 3.5 320 1250 1.2
    GV35 35 118 54 40 15 15 35 8 110 3.4 320 1250 1.2
    GV40 40 118 54 40 15 15 35 8 110 3.3 320 2180 1.2
    GV45 45 155 54 80 15 18 35 10 140 5.8 300 2180 2.2
    GV50 50 155 54 80 15 18 35 10 140 5.7 300 2180 2.2
    GV55 55 155 54 80 15 18 35 10 140 5.6 300 2180 2.2
    GV60 60 155 54 80 15 18 35 10 140 5.5 300 2180 2.2
    GV70 70 155 54 80 15 18 35 10 140 5.3 300 2180 2.2
    GV80 80 190 64 80 20 20 40 10 155 8.7 200 2930 3.5
    GV90* 90 260 90 120 25 30 50 20 220 24.5 150 7250 3.5
    GV100* 100 260 90 120 25 30 50 20 220 23.5 150 7250 3.5
    GV110* 110 260 90 120 25 30 50 20 220 22.5 150 7250 3.5
    GV120* 120 300 110 120 30 30 50 20 240 42 130 11100 6.0

    GV 40 Backstop Clutch One Direction Cam Clutch Roller Bearing
