| Brand Name : | LINK-PP |
| Model Number : | LPJK9072A110NL |
| Certification : | UL,ROHS,Reach,ISO |
The LPJK9072A110NL supports speed 10G Base-T, It is compliant to IEEE 802.3, UL, Reach, RoHs, ISO19001,ISO14001 standards.It can be used to support application, such as Intercom, Network Firewall, Switches and Server.
| LINK-PP Part Number: | LPJK9072A110NL | Connector Type | Jack |
| Part Status | Active | Mounting Type | Through Hole |
| Number of Positions/Contacts | 10p8c (RJ45, Ethernet) | Application-Lan | Ethernet(NoN PoE) |
| Number of Ports | 1x1 Port | Speed | 10G Base-T |
| Latch | Up | Cores per Port | 8 |
| Orientation | 90° Angle (Right) | PCB Mount Angle | SIDE ENTRY |
| Shield EMI Tabs | With | LED Option | Yellow&Green/Green |
| PCB | FR4 | PCB Retaining Post | T POST |
| Package Height (Inches/mm) | 0.445/11.30 | Package Length (Inches/mm) | 0.939/23.85 |
| Package Width (Inches/mm) | 0.700/17.78 | Temperature | 0℃ TO 70℃ |
| Bst Circuit | Yes | AutomDX | YES |
| Diodes | No | Contact Mating Area Plating | GOLD 6u"/15u"/30u" |
| Turns Ratio RX/TX | 1CT:1CT | Configuration RX/TX | T,C |
|
