    LPJM19434CNL 2.5G Base-T 1X1 Port Tab Up SMT RJ45 Magjack Female Connector Without Led

    Ask Lasest Price
    Brand Name : LINK-PP
    Model Number : LPJM19434CNL
    Certification : UL,ROHS,Reach,ISO
    • Product Details
    • Company Profile

    LPJM19434CNL 2.5G Base-T 1X1 Port Tab Up SMT RJ45 Magjack Female Connector Without Led

    LINK-PP LPJM19434CNL 2.5G Base-T SMT RJ45 Magjack Female Connector for Network Firewall and Smart Meters (Tab Up, Without Led)


    The LPJM19434CNL supports speed 2.5G Base-T, It is compliant to IEEE 802.3, UL, Reach, RoHs, ISO19001,ISO14001 standards.It can be used to support application, such as Monitoring System, Embedded Main Board, Network Firewall and Smart Meters.


    LINK-PP Part Number:
    LPJM19434CNLConnector Type
    Jack
    Part Status
    ActiveMounting Type
    Surface Mount
    Application-Lan
    Ethernet(NoN PoE)
    Cores per Port
    8
    Number of Ports
    1x1 PortSpeed
    10/100 Base-T
    Latch
    UpLED Option
    Without
    Orientation
    Right AnglePCB Mount Angle

    90°

    Shield EMI Tabs
    With


    PCB
    FR4PCB Retaining Post

    T POST

    Package Height (Inches/mm)
    0.536/13.61Package Length (Inches/mm)

    1.00/25.40

    Package Width (Inches/mm)
    0.634/16.10
    Temperature
    -40℃ TO 85℃
    Bst Circuit
    YesAutomDX

    YES

    Diodes
    NoContact Mating Area Plating

    GOLD 6u"/15u"/30u"

    Turns Ratio RX/TX
    1CT:1CTConfiguration RX/TX

    T,C
