    Electric Pneumatic Driven FK-JL6 Honey Paste Bottle Packing Piston Filling Capping Machine

    Ask Lasest Price
    Brand Name : FK-SPEEDA
    Certification : ISO9001
    Supply Ability : 1000 Set/Sets per Month
    Price : $13,000.00/sets 1-2 sets
    • Product Details
    • Company Profile

    Electric Pneumatic Driven FK-JL6 Honey Paste Bottle Packing Piston Filling Capping Machine

    Product Overview

    Features:

    The production line can widely used to filling,capping and labeling for various semi-liquid,ointment paste, dense catsup and various materials with granule, such as drinks with fruit, honey,syrup,jam, peanut butter, sesame paste,tomato sauce, peper sauce,etc.Operating principle By the reciprocating motion of the pistons in the material cylinders of the Filling Machine, negative pressure produces in the front chamber of the cylinder so that material could be pumped. The stroke of the cylinder is controlled by a signal valve so as to adjust filing amount and to achieve accurate filling results.Property The Filling Machine with extra functions is designed and manufactured by our factory with reference to the same kind of foreign machines.
    This machine is simpler and easier in operation, error correction, adjustment, cleaning and maintenance.With automatic
    transmission, automatic filling, no bottle no filling, bottle positioning, prevent drip, lifting filling, and other functions. Can
    be equipped with protective cover.The part contacting materials is made of 304 stainless steel.Material contact parts can be customized SS316.can install hopper. Hopper can be installed liquid level automatic control system.

    Optional Configuration

    1. conveyer; 2. CIP tank; 3. mix tank; 4. double jacket tank; 5. Plexiglass
    Application
    PRODUCT SPECIFICATIONS
    Model
    FK-JL6
    Filling range
    20-100ml,50-200ml,100-600ml,300-1000ml,500-2000ml
    Filling speed
    30~50 bottles per minute
    Power
    220V/50Hz 200W
    Filling accuracy
    Above(within):±1.5%
    Air Pressure
    0.4-0.6Mpa
    PRODUCT CONFIGURATION
    Guangdong Fineco Machinery Group Co., Ltd
    Guangdong Fineco Machinery Group Co.,Ltd. is a professional large-scale manufacturer of packaging machine,Integrating development and production together, Our main products include High-accuracy labeling machine, filling machine,capping machine,shrinkage machine, self-adhesive labeling machine and related equipment. Located in Chang'an Town, Dongguan City,Guangdong Province,China. we enjoy convenient land and air transportation.And with offices in Jiangsu Province, Shangdong Province,Fujian Province and other regions.
    Currently,Fineco is already exported to America,France,Australia,Germany and 50 other countries and regions. Our company has always focused on research,development and innovation,has obtained a number of patent certificates,and be rated as Chinese "Hight and New Technology Enterprise'in 2017 .we also attained ISO9001 and CE certifications.
    Fineco regards "Reasonable Prices,Efficient Production and Good After-sales Service "as our tenet.We hope to cooperate with more customers for mutual development and benefits. We welcome potential buyers to contact us.

    Production Workshop
    Our Team
