We are a Chinese MANUFACTURER which located in heze city,shandong
province,China, mainly produces medical machines.It is the 10th year for doing export.Welcome to visit.
The equipement is a new and full computer control system, it is a
high-speed production line, uses of advanced technology from
abroad, in the operation, the computer system monitoring the whole
production.
This machine has the following advantages:
High Production Speed: Instead of the low efficiency of band-aid equipments greatly,
reduces amount of labour used.KC-2000-B Band-aid packing machine,
the production speed is 0-1500 pieces/minute, the production speed
as multiple of 5-7 compared with ordinary machine, only needs one
operator.
Equipment Overall Configuration: The servo motor of this equipment is which made by Panasonic,
motion controller made by Panasonic.12 cun touch screen. Other
electrical equipment is Delixi Electrical Equipment. We put the
domestic and overseas advanced technologies to use, along with
long-term theory and practices programming. The equipment can
adjusted the medical pads to a right position automatically. The
materials of hobs are powder high-speed steel.The packaging of this
machine is stainless steel.
Gross weight of the machine is about 1 ton, it can ensure the
equipment running stability at the high speed.
Replacement Specification: The replacement band-aid specification only needs 20minutes, after
cutting tool installation, just input the size that you are needed
on the touch screen, it can producing normally.
Configuration Assistant:Prevent rolling devices is uses of magnetic powder, along-with
magnetic powder clutch, it can adjusted tension automatically, can
ensure the equipment running stability at the high speed.
Main Technical Parameters:
Machine Weight | 1.1 Ton |
Machine Power | 5.5KW |
Machine Dimension | 2.8MX0.8X1.8M |
Voltage | 220V---380V |
Production Speed | Normal 0-2000 pieces/minute |
Color positioning 800-1000 pieces/minute |
