    Roadway Safety Wave Beam Barrier Highway Guardrail Barrier Terminal W-beam Guardrail

    Ask Lasest Price
    Brand Name : Safebuild
    Model Number : 100*50
    Supply Ability : 12000 Ton/Tons per Month
    Price : $50.00/pieces 20-199 pieces
    • Product Details
    • Company Profile

    Roadway Safety Wave Beam Barrier Highway Guardrail Barrier Terminal W-beam Guardrail

    Products Description

    W Beam Highway Guardrail

    Guardrail is a kind of road crash barrier used for securing highway safety by preventing errant vehicles from sliding out of the roads and impacting the roadside buildings or other objects. So it is most commonly fixed on the side of the highways, dock areas,aisles, especially on curves and slopes for protection against run-off-road collisions.
    There are mainly two specifications of steel guardrail: W-Beam guardrail and Thrie-Beam guardrail, They are manufactured from Q235B or Q345B grade steel in 2.5-4mm base metal thickness as supplied by China Steel Limited.
    All products are hot dipped galvanized or powder coated after fabrication to meet the requirements of Chinese National Standards,AASHTO M180 Standard, SANA 1350 Standard and etc.

    Product Paramenters
    Number of Road Accessories per Kilometer
    Product
    Size
    (L * W * WW * WH * T)
    Post spacing: 4 m
    Quantity per KM
    Post spacing: 2 m
    Quantity per KM
    Coating Treatment
    W-beam
    4320*310*85*3/4 mm
    250 Pcs
    250 Pcs
    Hot Dip Galvanized:
    60-100μm;

    Powder spraying:
    Pre-Galvanized + Powder spraying 50-90μm;
    Round Post
    2150*140*4.5mm
    251 Pcs
    501 Pcs

    Spacer Block
    178*196*200*4.5mm
    251 Pcs
    501 Pcs

    Post Cap
    Φ140mm
    251 Pcs
    501 Pcs

    Washer
    76*44*4mm
    251 Pcs
    501 Pcs

    Bolts & Nuts
    M16*35mm
    2000 Sets
    2000 Sets

    Bolts & Nuts
    M16*45mm
    251 Sets
    501 Pcs

    Bolts & Nuts
    M16*150/170mm
    251 Sets
    501 Pcs

    Terminal End
    R160
    2 Pcs
    2 Pcs

    Notes
    1.Shape:Two waves, W-beam
    2.Normal Specification: 4320*310*83*3mm. Other different sizes are available.
    3.Highway guardrail Standards: JT/T281-2007,AASHTO M-180, RALRG620,SPS98S
    4.Steel Material: Q235, Q345, S235JR, S275JR, S355JR
    5. The thickness of the steel: 2.75mm, 3mm, 4mm or based on consumers’ request.
    6. Surface treatment: hot-dip galvanized and galvanized plastic spraying coating.
    7.Guardrail relevant parts: Post, Spacer (C,U,H,Z,Round, Square and Sigma types etc) and Fasteners, Bolts & Nuts,Terminal,Reflectors
    8. Certificate: ISO9001:2015
    Material
    Q235B,Q345B,Q355B,S235,S355,S355JR
    Base metal nominal thickness
    Class A: 2.67mm, Class B: 3.43mm or customized
    Zinc coating thickness
    Type I: 550g/m2, Type II: 1100g/m2, or customized
    Standards
    AASHTO M180
    Application
    Highway, High grade roads
    Base Material
    A572/Q345B/HA350/Q235B/A36/S355JR/S275JR
    W-Beam
    2320/3320/4130/4318/4320*308/310/311/312/315*2.5/2.6/2.67/2.7/2.75/2.76/2.8/3/4/5
    Thrie-Beam
    2320/3320/4128/4218/4318/4320*506/508/510*2.76/2.8/3/4/4.5/5
    Surface Treatment
    Hot Dip Galvanized or Powder Coated
    Galvanizing Thickness
    300g/m2 (40µ), 550g/m2 (80µ) or 610g/m2 (85µ) or 1100 g/m2 (160µ) or 1220 g/m2 (170µ) or customized
    Certificate
    AASHTO, AS/NZS, EN, ISO9001, ISO14000, SGS, CE, BV
    Feature
    Great corrosion resistant, high intensity, long and durable, low cost, higher security, environmental protection, etc.
    Other
    Other special specification as per client's requirement or drawings.
    American AASHTO-M180 Technical Standard W-beam highway guardrail
    TYPE
    Overall Length
    (mm)
    Effection Length
    (mm)
    Norminal Uncoated Thickness
    (mm)
    TYPE Ⅰ
    4130
    3810
    2.67
    TYPE Ⅱ
    4320
    4000
    2.67

    MECHANICAL PROPERTIES
    ◆Material grade: S355JR
    ◆Yield Point, minimum, 345Mpa (50000psi);
    ◆Tensile Strength, minimum 483Mpa (70000psi); and
    ◆Elongation, in 50mm (2 in.),minimum, 12 percent.

    NOTES
    ●Thickness of Zinc coating: 550g/㎡ or1100g/㎡;
    ●The beams may galvantzed before or after fabrication;
    ●We can customize the length and thickness according to customer requirements.


    Manufacturing Technique
    Details Images
    Roadside safety begins with installation of guardrail products from Safebuild, your expert highway guardrail supplier.
    Contractors prefer Safebuild W-Beam and Thrie-Beam guardrail for its easier installation and long service life. Safebuild highway safety products
    conform to AASHTO and ASTM specifications.
    We use prime steel in each guardrail design. A multi-stage cleaning process prepares the metal for galvanizing. Continuously galvanized steel ensures a consistent finish without sharp points or zinc build-up. Looking for a different finish for your safety guardrail? We offer black, painted epoxy coatings, or weathered steel as alternative finishes for aesthetic applications.
    We also provide guardrail end sections. These products help complete highway safety guardrail systems for every specification.With standard end sections and energy-absorbing guardrail end treatments for wood post or steel post designs, we can meet your full project requirements.
    Company Profile
    Established in 2015, Shandong Safebuild Traffic Facilities Co., Ltd. is located in Economic Development Zone of guan
    County,Liaocheng City, Shandong Province, China, which is near by jiguan Highway. specialized in manufacturing and exporting Highway Guardrail and accessories. Safebuild Traffic Facilities Co., Ltd. covers an area about 7,000 square meters, has 120 employees and 8 senior engineers. With an annual production capacity of 200,000 tons, Safebuild company has continuously invested in two Hot-dip galvanizing lines, two hot-dip aluminum production lines,two electrostatic spray production lines and one hot-dip coated production line. Our aim is to Safebuild people, with our professional, wholehearted and devoting spirits as well as our remarkable products quality and favorable service system , sincerely hope to work together with the vast number of clients!
    The company has advanced guardrail plate forming machine, which can realize the strip head removal, smoothing, punching,cutting,forming, leveling and other working procedure, so that the guardrail has good consistency, high processing accuracy, low production cost, which is widely recognized by the market.


    The company has an advanced production line of plastic spraying and hot-dip galvanizing for guardrail . According to the
    different construction environment, corresponding surface treatment can be adopted to achieve good corrosion resistance, moisture
    resistance and weather resistance.
    We are spreaded to 8,000 km since it is established around China and successfully exported to other countries, like Russia and
    Malaysia, Algeria, Singapore, South Africa, Mozambique, Ghana, Brazil, etc. We have been holding a scientific, rigorous, normative
    and standardized pragmatic style , and developing impeccable inspection organization to to make sure all of our products quality
    are in line with national standards, industry standards and enterprise standards. Safebuild people, with our professional,
    whole-hearted and devoting spirits as well as our remarkable products quality and favorable service system , sincerely hope to
    work together with the vast number of clients, create brilliant!
    Product Packaging
    Focusing on the export business of transportation facilities, the company has rich packing and packing experience for container loading. Among them, the guardrail plate is packed with steel wire rope, the post is transported by pallet, and the spacer and other guardrail accessories are shipped in ton package. This assembly method ensures that the products arrive at the destination port and is convenient for loading and unloading.
    The packing of guardrail adopts bundling method, which is convenient for loading and unloading. It can also keep the balance of containers and facilitate transportation.
    The packing of guardrail post adopts the well shaped binding method, which has strong firmness and is easy to be loaded and unloaded by forklift.
    We use ton bags or simple wooden cases for packing accessories of guardrail, which is convenient for loading and unloading, and installation after arrival.
    Installation Instructions

    Our Advantages


    1.Professional manufacturers and suppliers of safety protection products;
    2.The company has many years of export experience, the export share is about 50%;
    3.According to customer requirements, design, research and development, customized products;
    4.Provide one-to-one online installation guidance and 24-hour service hotline.

    FAQ

    1.Are you a factory or trading company?
    A:We are factory which has been in this field for more than 10 years.

    2.Where is your factory located? How can I visit there?
    A:Our factory is located in Liaocheng City, Shandong Province, China. All our clients, from home or abroad, are warmly welcome to visit us!

    3.Will you deliver the goods on time?
    A:Yes,we promise to provide best quality products and delivery in time no matter if the price change lot or not, Honesty is our company's tenet.

    4.How can I get your quotation as soon as possible?
    A:The email and fax will be checked in 24 hours, meanwhile, the skype will be online in 24 hours Please tell us the order
    information about quantity,Specification(steel type, material, size )and destination port, you will get the latest price.

    5.How about the sample if i need?
    A:The sample will be offered for free if you need, but the freight will be covered by our customer. If we have cooperation, the freight will be covered by our company.

    6.How about the MOQ?

    A:Generally, the trail order will be accepted.The MOQ can be confirmed according to the different products. For example, the MOQ of PPGI will be 10MT.

    7.How about the delivery time?

    A:Within 15-30 days after receiving the deposit or L/C at sight. Of course, the detail will be confirmed by the quantity and the different products.

    8.How to order?
    A:Please send us your purchase order by email. Or you can ask us to send you a proforma invoice for your order. We need to know the following information for your order.

    9.What is shipment terms?
    A:1. Container ship 2. bulk ship 3. Train

    10.Do you have English Mill Test Certificates?

    A:Yes,that is what we give certificates to our clients.
