    high precision filling machine peristaltic pump,dispensing Peristaltic Pump

    Product Description

    Mini dithiophosphate filling and dispensing Peristaltic Pump

    Model: BT100J-1A



    Introduction

    BT100J-1A Precise peristaltic pump can be loaded pump head YZ15, YZ25,DG-1 and DG-2. and It can supply flow rates from 0.0002 to 380 ml/min. The motor speed can be adjusted manually or automatically through external control. Store the running parameters automatically. very easy to operate.It is the best selling economical peristaltic pump.


    - Speed: 0.1 to 100 rpm, reversible
    - Speed precision: 0.1 rpm
    - Speed control: Membrane keypad
    - Display: 3-digit LED displays current rpm
    - Communication interface: RS485
    - External control: Start/stop, cw/ccw control and speed control 0-5 V, 0-10 V, 4-20 mA and 0-10KHz
    - Power supply: AC 90V-260 V 50/60 Hz
    - Power consumption: ≤30 W
    - Operating condition: Temperature 0 to 40 ℃
    - Relative humidity < 80%
    - Dimensions (L×W×H): 243×151×157 (mm)
    - Drive weight: 2.5kg
    - IP rating: IP 31


    Technical Data Sheet

    Pump headModelAvailable tubingflow rate range (ml/min)
    YZ15-l3A13#, 14#, 19#, 16#, 25#, 17#, 18# wall thickness:1.5mm0.07-380ml/min
    YZ25-l3A15#, 24# wall thickness:2.5mm0.2-270ml/min
    DG10-lAwall thickness:0.8-1.0mm
    ID≤3.17mm
    A Refers to 6 rollers; B refers to 10 rollers
    0.00025-48ml/min
    DG10-1B0.0002-32ml/min
    DG10-2A0.00025-48ml/min
    (Single channel)
    DG10-2B0.0002-32ml/min
    (Single channel)
    BZ25-lA24#
    wall thickness:2.5mm
    0.26-260ml/min

    Tubing details

    Suitable pump head


    Accessories

    CE certificate

    Web:www.avtechnology.co.uk

    TRACKING No:GB/1067/4817/13


    OEM option

    Packaging & Shipping

    1Piece in carton with foam plastic foam.


    Usually , the pumps will be delivered by DHL, TNT or UPS.

    Our Services

    1 year warranty for all of our pumps
