2711R-T10T 2711RT10T AB AB PanelView 800 HMI Terminal

2711R-T10T 2711RT10T AB AB PanelView 800 HMI Terminal

⇒ Click here for good price 2711R-T10T

Contact Us

Email: miya@mvme.cn (CLICK)

QQ: 2851195450

Tel: 86-18020776792(CLICK)

Skype:miyazheng520(CLICK)

Product Details

The AB 2711R-T10T PanelView 800 HMI Terminal is an operator interface with the Windows CE 6.0 operating system which allows users to graphically view the machine status and to monitor and manage machine functions. Users can input and set the machine’s parameters through the 65K color trans-missive, thin-film transistor color active matrix, 10-inch LCD screen with a display dimension of 8.31in x 6.24in and a resolution of 800 x 600 pixel. The 2711R-T10T has an analog resistive surface touch and a LED backlight with a standby time of up to 40,000 hours. It has a battery-backed real-time clock with a battery lifespan of 5 years when used at a temperature below 77 °F. It also has a factory-built internal cache memory of 256 MB for storing the user settings and application parameters.

The 2711R-T10T is also fitted with a 256-MB Synchronous DRAM for application processes with a processor speed of 800MHz and it is compatible with MicroLogix and Micro 800 Controllers. The 2711R-T10T uses the isolated RS-232 and RS-422/RS-485 serial communication ports for data transmission and for programming by a PC using the Connected Components Workbench Software version 8.0 or later, which is compatible with Microsoft Windows 8.0 and 8.1. It also supports a USB 2.0 host port for connection to external peripheral devices and a micro SD card slot for an external memory of up to 32 GB. The 2711R-T10T has dimensions of 8.9 x 11.3 x 2.2 in and it weighs approximately 10lb. It is designated with the T4 temperature code and has a functional temperature of 0-50 °C (32-122 °F) with a NEMA/UL Type 4X, 12, 13, and IP65 enclosure type rating and a front bezel protection feature.

Why choose us

1. We will provie you the product info and picuture
2.Large stock, fast delivery
3.Competitive prices and immdiate quotation
4.Professional service,professional technical support
5. Warranty time is one year.
6. Strict test machine before shipment.
7. We could help you to get any components which is difficult to get
