| Brand Name : | TOPO |
| Model Number : | RAL1011 |
| Certification : | CE, ROHS, BV |
| Price : | Negotiable |
| Payment Terms : | L/C, T/T, Western Union, MoneyGram |
| Supply Ability : | 400 T/Month |
| Delivery Time : | 7 days |
RAL1011 brown beige electrostatic Outdoor UV-Resistant Pure Polyester Powder Coating
Mainly made of polyester resin and curing agent, leveling agent, pigment, filler and other addictives. Also call weatherability powder coating or outdoor type powder coating.
These are used where the application is indoor, away from direct
sunlight and where chemical resistance is required. The coating is
smooth with no orange peel. The curing schedule is normally 12 to15
minutes @ 190-200ºC metal temperature.
| Color | RAL and PANTONE or customized |
| Gloss range | High/low/matt |
| Surface | sandy,wrinkled,hammer tone,metalic effect,woodeffect and etc |
| Particle size | Average 32 42um |
| Curing condition | 190 (object temperature) for 15 minutes |
| Coverage | 6-7 square meters per KG at 120um film thickness |
| Sheif life | 10 months in closed bag bellow 25 |
| Packaging | Polyethylene bag(inner) and paper carton(outer) |
| Storage | Stored in closed packages with dry environ ment below 25 |
Film Propert
| Testing items | Standards | Methods | Test index |
| Iimpact strength | ISO 6272 | GB1732-1993 | 40cm |
| Bending resistance | ISO 1519 | GB/T6742-1986 | 3mm |
| Adhesion | ISO 2409 | GB/T9286-1998 | Grade 0 |
| Cupping test | ISO 1520 | GB/T9753-1988 | 5mm |
| Pencil hardness | ASTM D3363 | GB/T6739-1996 | H-2H |
| Salt spray test | ISO 7253 | GB/T1771-1991 | More than500 hours |
| H&humidity test | ISO 6270 | GB/T17740-1979 | More than1000 hours |
| Weatherability | ASTM G151 | GB/T1865-1997 | 240(QUV B313) |

|
