    Zincalum 5V Twin Ribs Roof Sheet Roll Forming Machine Roofing Tile Panel Making Machine

    Ask Lasest Price
    Brand Name : Sussman
    Model Number : SM-RP
    Certification : CE ISO SGS
    Price : negotiable
    Payment Terms : T/T L/C
    Supply Ability : 10 sets per months
    Delivery Time : 65 days after deposit
    • Product Details
    • Company Profile

    Zincalum 5V Twin Ribs Roof Sheet Roll Forming Machine Roofing Tile Panel Making Machine

    Zincalum 5V Twin Ribs Roof Sheet Roll Forming Machine


    These low-maintenance, aluminum roofing and siding panels offer an attractive appearance and extra durability, complementing your agricultural structure for years to come. To see if Twin Rib panels are the right fit for your agricultural application, get in touch with us!

    An exposed fastener panel made with 100% recyclable aluminum, Twin Rib can be used in a range of agricultural applications, including animal confinement.

    Technical parameter:

    NumberItemsUnitTypeRF-DL
    1Steel Thicknessmm0.12-0.3mm 0.3-0.8mm PPGI and GI
    2Forming line Speedm/min10-12
    3Roller standsstandAbout 20-22stands
    4Roller Materialmm#Gcr15, coated with hard chrome quenching
    Shaft material and diametermmФ76 45# steel, coated with chrome
    5Main Motor PowerKw7.5
    6Hydraulic cutting PowerKw4
    7Hydraulic pressureMpa12
    8Power Supply415V, 50HZ,3 phase
    9Tolerancemm+/-1.5
    10Material of cuttingCr12mov HRC60-62
    11Control systemPLC with touch screen
    12Machine net weightT8
    13Out sizemm10000*1300*1000


    Machine List


    Machine list5 tons hydraulic de-coiler1 set
    Main roll forming machine1 set
    PLC Control box1 unit
    Hydraulic station1 unit
    Safety cover1 set
    Spare parts1 set

    working flow



    Profile Drawing


    Machine Shows



    Application:
