Product Description:
Animal Sera Filling Machine is a special equipment for automatic
filling of animal sera. It is widely used in the production of
animal blood and serum products. The whole line of equipment is
designed and manufactured according to the requirements of GMP. It
has high safety, high precision, high automation, and reliable
performance. The main features of the Animal Sera Filling Machine
are as follows:
- Air Pressure: 0.6-0.8Mpa
- Security: 304 Stainless Steel Frame, Tempered Glass Cover. Open The
Door To Stop; Emergency Stop Device, Earth Leakage Protection. HEPA
Can Be Installed
- Working flow: Bottle Loading On Powered Platform (unpacking
Station)→ Screw Positioning Bottle → De-capping → Weighing I →
Peristaltic Pump Filling→ Weighing II And Capping→Automatic
Rejection Station→Finished Products To Packing Area→ Automatic
Sleeve Labeling → Heat Shrinking Machine → Single Side Labeling
Machine→Bottle Collection Platform
- Power Consumption: 10KW For Whole Line
- Printing: Zebra Thermo Transfer Printer
The Animal Sera Filling Machine is equipped with advanced control
system and operation interface. It can display the operating
parameters and data in real time. The machine has high precision
filling and capping. It is equipped with a weighing system to
ensure accurate filling. It is fast and stable in production, and
it can meet the requirements of GMP. All materials in contact with
the product are made of 304 stainless steel and will not
contaminate the product. The Animal Sera Filling Machine can be
used for the filling of animal sera, animal blood, and other liquid
products.
Features:
- Product Name: Animal Sera Filling Machine
- Buffer bag: Single Use Buffer Bag With Pipes And Filling Nozzles
- PLC: Siemens 1500
- Filling Nozzle: Five/Six/Seven/Eight
- Filling method: 5 Sets Of OEM Peristaltic Pumps, Watson-Marlow 505L
Pump Heads, Driven By Servo Motors. Set And Adjust The Filling
Volume On The Touch Screen
- Special Feature: Animal Sera Aseptic Filling Device, Animal Blood
Filler, Fetal bovine serum filling machine
Technical Parameters:
| Property | Value |
|---|
| Filling method | 5 sets of OEM peristaltic pumps, Watson-Marlow 505L pump heads,
driven by servo motors. Set and adjust the filling volume on the
touch screen |
| Weighing unit | Mettler load cell + controller. Marble floor installation
foundation |
| Capping head lift | Servo motor control |
| Power consumption | 10KW for whole line |
| Product name | Animal Sera Filling Machine |
| Dimension | 3000*900*1800mm |
| Environmental monitoring | Online particle and planktonic monitoring system |
| Material | Stainless steel |
| Pneumatic components | SMC or Festo |
| Weight | 1000kg |
| Keywords | Animal serum filler, Animal plasma filling machine, Animal sera
aseptic filling device |
Applications:
The Animal Serum Filling Machine, produced by PERWIN with model
number PW-ZWGX550, is a highly effective and reliable FBS filling
machine. It is ISO, GMP, UL, TUV, SGS certified and is available in
minimum order quantity of 1. The price of the machine is
negotiable, and it is packaged using Export Standard Wooden Cases.
It is delivered within 60 working days after payment. The company
can supply 10pcs/month. It comes with torque control method of
Servo Technology, with 5 Sets Of Capping Units, Each Set Of Servo
Motors Are Individually Controlled, Clockwise Capping And
Anti-clockwise Capping. It has a filling head of
Five/Six/Seven/Eight and filling accuracy of ±0.5~1%. The dimension
of the machine is 3000*900*1800mm. It is manufactured in Qidong,
Jiangsu.
Customization:
Animal Sera Aseptic Filling Device is a high-tech product manufactured by PERWIN with model number
PW-ZWGX550. It is certified with CE, ISO, GMP, UL, TUV and SGS, and
the minimum order quantity is 1. The price is negotiable, and it is
packaged in export standard wooden cases. The delivery time is 60
working days with payment term of TT. The supply ability is
10pcs/month. It adopts a set of servo motor drive screw for
positioning, with dimension of 3000*900*1800mm. It also comes with
single use buffer bag with pipes and filling nozzles. The filling
temperature ranges from 0 to 100℃, and the printing system is Zebra
thermo transfer printer. It is suitable for filling fetal bovine
serum and animal plasma aseptic filling line.
Support and Services:
Animal Sera Filling Machine Technical Support and Service
We provide comprehensive technical support and service for Animal
Sera Filling Machine. Our experienced team is available to provide
rapid, reliable assistance for installation, operation,
maintenance, troubleshooting, and other technical issues. We offer
service and parts for a wide range of Animal Sera Filling Machine
products.
Our service capabilities include:
- On-site installation and maintenance
- Remote troubleshooting and support
- Training for operators and technicians
- Replacement parts and components
We are dedicated to keeping your Animal Sera Filling Machine
running optimally and efficiently. Contact us today for more
information about our technical support and service options.
FAQ:
- Q: What is the Brand Name of Animal Sera Filling Machine?
- A: The Brand Name of Animal Sera Filling Machine is PERWIN.
- Q: What is the Model Number of Animal Sera Filling Machine?
- A: The Model Number of Animal Sera Filling Machine is PW-ZWGX550.
- Q: Where is Animal Sera Filling Machine made?
- A: Animal Sera Filling Machine is made in Qidong, Jiangsu.
- Q: What certifications does Animal Sera Filling Machine have?
- A: Animal Sera Filling Machine has CE, ISO, GMP, UL, TUV, SGS
certifications.
- Q: How many Animal Sera Filling Machine can I order?
- A: The minimum order quantity of Animal Sera Filling Machine is 1.
