Product Description:
1.Geared up with 55kw yuchai organisation turbocharged engine with
robust strength;
2.Patented graph compound increase, double cylinder lifting;
3.Every drilling rig is geared up with a baffle on the major arm to
shield the oil cylinder;
4.Drilling rig chassis: specialist excavator chassis, strong and
sturdy, heavy-obligation, vast chain plate, the drilling rig makes
use of rubber tracks, excessive flexibility, much less damage to
challenging roads.
5.Parallel transmission design, unbiased oil pump, sufficient
strength, cheap distribution, unique hydraulic machine design, easy
preservation and espresso fee.
6.The working computing machine is convenient and handy to operate
7.Easy to load and dump on the truck
8.Dual structures may additionally be brought: 1. air electrical
energy laptop with air compressor two mud pump gadget with grime
pump
Product display:



| The weight | 4.5T |
| Dimension | 3950*1630*2250mm |
| The hole diameter | 140-254mm |
| Drilling depth | 180m |
| One-time advance length | 3.3m |
| Walking speed | 2.5KM/H |
| Climbing angles | 30 |
| Power | 55kw |
| Using air pressure | 1.7-2.5MPA |
| Air consumption | 17-31 |
| Drill pipe length | 1.5m 2.0m 3.0m |
| Drill pipe diameter | 76mm,89mm |
| Rig lifting force | 12T |
| Swing speed | 45-65rpm |
| Swing torque | 3200-4600N.m |
|
