Product Description:
Petri Dish Filling Machine is an automatic filling apparatus which
is assembled by Perwin and consists of 6 sets of peristaltic pumps,
each driven by a separate stepping system. The filling
specification and accuracy can be selected on the host's touch
screen interface and adjusted independently. The preparation tank
is available in 30L, 60L and 100L agar sterilization reactors and
is suitable for a variety of agars with or without blood and/or
supplements. The agar sterilizers should be operated at 121°C for
at least 15 minutes and then cooled to 38-45°C and held steady for
at least 8 hours. The fluid input port should be equipped with the
highest accuracy thermometer and multiple level mixers. The noise
level of the machine is ≤75dB while the pure steam generator has a
capacity of 100kg/h.
Features:
- Product Name: Petri Dish Filling Machine
- Dish stacking: Integrated Servo Sinking And Stacking Unit
- Light: Install 4 Sets Of Lighting On The Main Line
- PLC: SIEMENS From Germany
- Dish separating: The Dish Separation Mechanism, Upper Suction Cap
Mechanism, And Cap Moving Mechanism All Adopt Servo Technology
- Filling volume: 20ml~25ml
- Petri Dish Filling Apparatus
- Petri Dish Filling Equipment
- Petri Dish Filling Robot
Technical Parameters:
| Parameter | Description |
|---|
| Warranty | 1 Year |
| Weight | 2000kgs |
| Dish stacking | Integrated Servo Sinking And Stacking Unit |
| Preparation tank | 30L, 60L And 100L Agar Sterilization Reactors Per Line (specific
Requirements Are As Follows.) Agar Sterilizers Will Be Used To
Prepare A Variety Of Media, With Or Without Blood And/or
Supplements. Therefore, Jars Should Be Sterilized For Agar At 121°C
For At Least 15 Minutes. Then Cool To 38-45°C And Hold This
Temperature Steady For At Least 8 Hours. With Fluid Input Port The
Thermometer Should Be Of The Highest Accuracy, The Mixer Should
Have Multiple Levels, Say These Are The Basic Requirements, The
Tank Will Be For A Variety Of Agars, Not A Specific Few. |
| Capping method | Servo Technology Control Fixed-point Cap Closing. |
| Safety Protection | SS304 Frame, Tempered Glass |
| Bi-plates filling | Servo Mechanism Orientation Unit. |
| Format changing time | Within 30mins |
| PLC | SIEMENS From Germany |
| Inner bag packing | Automatic Packing Machine |
Applications:
PERWIN's PW-PP6-10000 Petri Dish Filling Machine is the perfect
equipment for an automated laboratory. Manufactured in Qidong,
Jiangsu, this machine has been certified by CE, ISO, GMP, UL, TUV
and SGS to ensure the highest safety and quality standards. It is
equipped with a dish separation mechanism, upper suction cap
mechanism and cap moving mechanism, all of which adopt servo
technology for superior accuracy and efficiency. Additionally, the
dish shaking mechanism is supported by a servo motor control to
provide precise motion control.
The preparation tank also offers excellent performance with its
30L, 60L and 100L agar sterilization reactors. The tank is capable
of sterilizing a variety of media, with or without blood and/or
supplements, and is equipped with a fluid input port and
thermometer of the highest accuracy, as well as a mixer with
multiple levels.
PERWIN's PW-PP6-10000 Petri Dish Filling Machine is available for
purchase with a minimum order quantity of 1 and at a negotiable
price. It is delivered in export standard wooden cases within 60
working days and payment terms are TT. The machine weighs 2000kgs
and has a filling accuracy of ±1~3%. With a supply ability of
10pcs/month, this Petri dish filling machine is sure to meet your
laboratory needs.
Customization:
Welcome to PERWIN's Petri Dish Filling Machine. Our machine, model
number PW-PP6-10000, is made in Qidong, Jiangsu and certified with
CE, ISO, GMP, UL, TUV, and SGS standards. The minimum order
quantity is 1 and the price is negotiable. It is shipped in export
standard wooden cases and the delivery time is 60 working days.
Payment is accepted via TT and the supply ability is 10pcs/month.
This machine has a filling speed of 4000~4500dishes/hour and is
equipped with a servo mechanism orientation unit, with a total
weight of 2000kgs. It also comes with a sheep blood adding system,
which includes one peristaltic pump, blood bag storage rack, and
exclusive FFU area, with sheep blood placed on a special shelf
(with casters).
Support and Services:
Technical Support & Services for Petri Dish Filling Machine
At ABC Company, we provide technical support and services for our
Petri Dish Filling Machine to ensure your machine runs efficiently
and effectively.
Installation & Setup
Our team of certified technicians can provide professional
installation and setup of your Petri Dish Filling Machine, ensuring
it is set up correctly and is operating as expected.
Maintenance & Repair
We offer ongoing maintenance and repair services for your Petri
Dish Filling Machine. Our technicians can identify any issues and
take the necessary steps to repair or replace any faulty parts.
Troubleshooting & Support
We provide 24/7 troubleshooting and support for your Petri Dish
Filling Machine. Our experienced team is always available to answer
any questions or address any issues you may have.
FAQ:
- Q: What brand is the Petri Dish Filling Machine?
- A: The Petri Dish Filling Machine is a PERWIN brand.
- Q: What is the model number of the Petri Dish Filling Machine?
- A: The model number is PW-PP6-10000.
- Q: Where is the Petri Dish Filling Machine made?
- A: The Petri Dish Filling Machine is made in Qidong, Jiangsu.
- Q: What certifications does the Petri Dish Filling Machine have?
- A: The Petri Dish Filling Machine has CE, ISO, GMP, UL, TUV, and
SGS certifications.
- Q: What is the minimum order quantity for the Petri Dish Filling
Machine?
- A: The minimum order quantity is 1.
