3-8V8 Duct Collector Remote Pilot Valve Enclosures Controller

    Buy cheap 3-8V8 Duct Collector Remote Pilot Valve Enclosures Controller from wholesalers

    Buy cheap 3-8V8 Duct Collector Remote Pilot Valve Enclosures Controller from wholesalers
    • Buy cheap 3-8V8 Duct Collector Remote Pilot Valve Enclosures Controller from wholesalers
    • Buy cheap 3-8V8 Duct Collector Remote Pilot Valve Enclosures Controller from wholesalers

    3-8V8 Duct Collector Remote Pilot Valve Enclosures Controller

    Ask Lasest Price
    Brand Name : BRANDO
    Model Number : 3-8V8
    Certification : CE, ISO
    Price : Negotiation
    Payment Terms : T/T, PayPal, Western Union
    Supply Ability : 10000pcs per month
    Delivery Time : 4-7 working days
    • Product Details
    • Company Profile

    3-8V8 Duct Collector Remote Pilot Valve Enclosures Controller

    3-8V8 Duct Collector Remote Pilot Valve Enclosures Controller


    Diecast aluminum enclosures for Goyen RCA3D pilot valves. The enclosures for non-hazardous locations offer reliable protection for your pilot valves and remote actuators. The enclosures were specifically designed for convenient piloting of dust collector cleaning system pulse jet valves. Ensure device is disconnected from power before opening the enclosure. For reliable operation, ensure supply voltage is within -10% and +15% of rated solenoid voltage.


    Ordering Code of RCA3D Pilot Valve Enclosure:


    Video of 3-8V8 Pilot Valve Enclosure:


    Main Dimension of 3-8V Pilot Valve Enclosure:


    Technical Data of RCA3D Solenoid Pilot Valve:

    Model
    Port Size
    Coil Type
    Voltage
    Power
    RCA3D0-330
    (Old RCA3D2-T-QT/1392B)
    1/8'' NPT
    Screw / Spade
    200/240V 50/60Hz
    17.4/22.6VA
    RCA3D0-331
    (Old RCA3D2-T-QT/1004B)
    100/120V 50/60Hz
    15.2/149.7VA
    RCA3D0-332
    24V 50/60Hz
    23.1/17.2VA
    RCA3D0-333
    240V DC
    24W
    RCA3D0-334
    110V DC
    24W
    RCA3D0-335
    48V DC
    20W
    RCA3D0-336
    (Old RCA3D2-T-QT/764B)
    24V DC
    20W
    RCA3D0-337
    (Old RCA3D2-T-QT/1295B)
    12V DC
    20W
    RCA3D1-330
    (Old RCA3D2-T-QT/880B)
    1/8'' BSPP
    200/240V 50/60Hz
    17.4/22.6VA
    RCA3D1-331
    (Old RCA3D2-T-QT/869B)
    100/120V 50/60Hz
    15.2/149.7VA
    RCA3D1-332
    (Old RCA3D2-T-QT/1117B)
    24V 50/60Hz
    23.1/17.2VA
    RCA3D1-333
    240V DC
    24W
    RCA3D1-334
    110V DC
    24W
    RCA3D1-335
    48V DC
    20W
    RCA3D1-336
    (Old RCA3D2-T-QT/1051B)
    24V DC
    20W
    RCA3D1-337
    12V DC
    20W

    More Goyen Type Pulse Valves for you to choose:

    1345
    T SeriesDD SeriesFS SeriesMM Series
    2Goyen Coil1Goyen Diaphragm
    RCA SeriesSolenoid CoilSolenoid ArmatureDiaphragm


    Focus on your demands, Offer you best solution:


    √ Contact us if some points you have doubt

    √ Contact us if somewhere need to change
    √ Contact us if not the one you are looking for

    √ Contact us if you are doing designing
