Fire Resistant 1.5mm SDI Single Core Double Insulated Electrical Wire 450/750V PVC/PVC (RED/WHITE)

Ask Lasest Price
Certification :	ISO9001, CCC, RoHS, SAA
Supply Ability :	50000K Meter/ per Month
Brand Name :	Qifan
Price :	usd3-8/meter
Delivery Time :	30-45days
Payment Terms :	D/A, D/P, L/C, T/T, Western Union, MoneyGram

Add to Cart

Product Details
Company Profile

Fire Resistant 1.5mm SDI Single Core Double Insulated Electrical Wire 450/750V PVC/PVC (RED/WHITE)

Product Description

PVC Sdi Cable, 450/750 V, 1/C, Australian Cu/V-90/PVC Power Cable (AS/NZS 5000.2)

Application: Fire Resistant - Mains and Sub-Mains, Fire Alarm Systems, Essential Services

Construction:
1. Conductor - Plain annealed class 5 flexible copper
2. Fire Resistant layer - Mica Tape
3. Insulation - Cross-linked low-smoke halogen-free polyolefin compound (X-HF-110)
4. Outer sheath - Cross-linked low-smoke halogen-free polyolefin compound (HFS-110-TP)

Cross Section:
1 core: 1.5~630mm2

Temperature characteristics:
Conductor operating temperature: -40ºC~110ºC
Min. temperatrue laying condition: 0ºC

Electrical Characteristics:
Rated voltage: 0.6/1 (1.2) kV
High voltage test: 3.5kV / 5min

Color:
Insulation: White or according to customer requirements
Sheath: Red or according to customer requirements

Standard:
Cable design: AS/NZS5000.1
Conductor: AS/NZS 1125
Fire resistant : AS/NZS3013 (WS52W)

Cond. Area mm	Stranding No/mm	Insulation Thick mm	Sheath Thick mm	Nom.O/D mm	Min. Installed Bending Radius mm	Approx. Mass Kg/Km	Order Now
1	1x1/1.13	0.6	0.8	4.1	20	30
1.5	1x7/0.50	0.6	0.8	4.5	20	40
2.5	1x7/0.67	0.7	0.8	5.2	25	55
4	1x7/0.85	0.8	0.9	6.2	25	80
6	1x7/1.04	0.8	0.9	6.8	30	100
10	1x7/1.35	1	0.9	8.2	35	145
16	1x7/1.70	1	1	9.4	40	225

Other sizes can also be produced as you required.

Size	Conductor Strands	Insulation Thickness
2x1.5mm2	7/0.52mm	0.6mm
2x2.5mm2	7/0.68mm	0.7mm
2x1.5mm2+1.5mm2	7/0.52mm	0.6mm
2x2.5mm2+2.5mm2	7/0.68mm	0.7mm
2x4mm2+2.5mm2	7/0.85mm+7/0.68mm	0.8mm
2x6mm2+2.5mm2	7/1.04mm+7/0.68mm	0.8m

------Our Feature------

Imported equipment with experienced technical team
The company have three plant and has 3048 employees which have 206 engineers. Plant has a series of imported production lines including Niehoff copper drawing lines, Troster Germany and Maillefer Finland 500KV VCV lines, stranding machine from Pourtier France, SKET Germany, Caballe Spain, 220KV and 35KV production line plus SIKORA X - RAY 8000 on-line eccentricity measuring unit from Germany
Complete certification system
Qifan Cable have gotten ISO 9001, ISO 14001, OHSAS 18001. Plant passed TUV, VDE, UL, CE, SAA, BS etc. certificate.
Perfect Production system
Qifan Cable products cover LV power cable, MV power cable, HV&EHV power cable, ABC cables, ACSR/AAC/AAAC/ACAR/OPGW ,submarine cable, control cable, instrumentation cable, building wire, flexible rubber cable, fire rated cable, renewable cable, solar cable, industrial cable, Lan cable, coaxial cable etc.
Perfect Sales service system
Qifan Cable can offer the OEM/ODM service, Multiple products, Skilled Export sale engineer team, Reasonable price, Reliable quality, Friendly service. Qifan is always your best choice.
