Beryllium Strips БрБ2 Soft Strips And Hard Strips Acoording
Standard ГОСТ 1789
Product Description:
| Material Grade | БрБ2, Qbe2.0 Cube2, C17200, Alloy 25 |
| End product | Strip, Tape |
| Thickness | 0.1mm, 0.15mm, 0.12mm,. 0.2mm, 0.25mm, 0.3mm, 0.4mm, 0.5mm, 0.6mm,
0.8mm and so on |
| Width | 200mm, 250mm or 300mm |
| Coil Weight | We could do it as per customers' requirement, normal is 100kgs |
| Temper | Soft, Hardness ＜130HV |
| Hard Hardness ＞170HV |
Chemical Composition of Beryllium БрБ2:
| CUBERYLLIUM® Brand | Gost- Number | Be | Al | Ni | Fe | Cu | Si |
| Cuberyllium-Qbe2 | БрБ2/Qbe2 | 1.80-2.10 | ≤0.15 | 0.2~0.5 | ≤0.15 | Rest. | ≤0.15 |
Properties of Beryllium БрБ2:
Beryllium БрБ2(Cube2) is called high-alloy beryllium bronze,
because it contains about 2% beryllium.
Beryllium БрБ2(Cube2) is the most commonly used alloy of the Cu-Be system, the end
products includes strips, foils, tapes, wires, rods, tubes and
plates.
Beryllium strip, beryllium foil, beryllium tapes, beryllium tube
and beryllium rods are the most popular products in the Russian
Market.
We have sales experience to Russian Market, and have the bank
account to receive the payment from Russia, we could get it around
1~2 working days.
So it will rush the production arrangment and the delivery time.
We have own forwarder for Russian Market, could provide CIF Terms
to Russia.
Any inquiry, just feel free to contact with us:
By Email: sales@cuberyllium.com
By What'sApp: +86 15868495251
By Skype: +86 15868495251
Beryllium is a lightweight and strong metal that has a range of
special characteristics:
- With low density around 8.36g/cm3
- High thermal conductivity
- High strength
- Excellent dimensional stability
- High electrical conductivity
- High corrosion resistance
- High modulus of elasticity
- High resistance to fatigue
All these good properties, make the beryllium copper alloys ideal
for use in a variety of areas.
The largest application area of beryllium copper alloys is
electrical and electronic parts, but also it is used in automotive
industry, drilling&Oil production equipment, Resistance
welding, Casting of metals and alloys, Aviation Engineering and so
on.
| Some Applications of Copper Beryllium БрБ2 |
| Spring contacts | Switches |
| Drilling equipment | Oil production equipment |
| Electro-mechanics | Connectors |
| Aeronautics | Injuected plastics |
| Mechanics | Seam weldind discs (wheels) |
FAQ:
| Q1:Could you accept small coil wight for the strips and foils? |
| A1:Yes, sure. The normal coil weight is 100kgs, but we could help
to divided it to 50~70kgs according customers' requirement. Also
some customer requests 5kg/10kg, we could help to slit it. |
| Q2: What’s the advantages the Beryllium Copper of CUBERYLLIUM®. |
A2: 1: Quick production schedule; 2:With wide range of the product, including БрБ2 strips, foils, tapes, tubes, wires, rods and plates. We also
provide BrBNT1.9 strips, tapes and foils; 3:Service for customers before the purchase and after the purchas; 4: Small qty acceptable. |
| Q3: Can you ship the material by your forwarder? |
| A3:Yes, sure. We have the russian market forwarder, could provide
the CIF term to train station in Russia. |
| Q4: Do you have the account to accept the payment from Russia? |
A4: Yes, we have the bank account, can receive the payment quickly,
around 1~2 days. So that we could arrange the production earlier for our customers,
and delivery the material immediately. |
Product Photo:
