    Rubber Two In One Ceramic Abrasion Resistant Liner Thickness 5mm

    Ask Lasest Price
    Brand Name : Ibeno
    Certification : ISO9001-2015
    Price : Negotiable
    Model Number : Rubber Ceramic Liners
    Delivery Time : 25-45 workdas
    Payment Terms : T/T
    Supply Ability : 100,000 ㎡/ year
    • Product Details
    • Company Profile

    Rubber Two In One Ceramic Abrasion Resistant Liner Thickness 5mm

    Product Description

    Ceramic rubber abrasion-resistant liner is a composite wear-resistant ceramic rubber plate of ceramic rubber that adopts an advanced thermal vulcanization process to vulcanize square or hemispherical wear-resistant ceramic lining and rubber together. It combines the advantages of the high hardness of ceramics and the high cushioning and anti-fatigue properties of rubber, and can well solve the problem of equipment wear resistance in the process of conveying large pieces of boring. The addition of rubber not only makes the composite board have good anti-wear and anti-corrosion effects but also can prevent production stoppage and reduce noise caused by material accumulation.

    Installation Process

    The abrasion-resistant liner plate can only be operated according to the strict pasting process to achieve the effect of the ceramic sheet being firm and not falling off. First, use a sandblasting gun, a corner machine, or a wire brush to clean the surface to adhere to make it appear metallic luster. The rougher the cleaner, the better the paste effect. Then use alcohol to clean the surface to be adhered to remove the oil stains on the surface; evenly mix the adhesive in a certain proportion, apply it on the surface to be pasted, and then tap the wear-resistant ceramic linings one by one with a rubber hammer to make them in close contact.


    Scope of application

    -Adaptable temperature: -40℃~150℃

    -Objects of use: anti-wear linings for various equipment and pipelines (such as blanking troughs, hoppers, chutes, forklift shovels, coal drop hoppers, ball mill inlet and outlet pipes, coal drop pipes, etc.)


    Product Selection (part)

    Ceramic + rubber two-in-one liner (can be customized according to customer requirements)

    NoCeramicRubberTotal thickness
    15mm5mm10mm
    25mm7mm12mm
    37mm7mm14mm
    47mm5mm12mm
    58mm6mm14mm
    610mm5mm15mm
    712mm7mm19mm
    812mm5mm17mm
    912mm8mm20mm
    1015mm10mm25mm

    Ceramic+rubber+steel plate three-in-one liner

    NoCeramicRubbersteel plateTotal thickness
    16mm5mm6mm17mm
    27mm8mm6mm21mm
    37mm6mm5mm18mm
    47mm7mm6mm20mm
    58mm7mm6mm21mm
    69mm6mm6mm21mm
    710mm5mm6mm21mm
    810mm5mm5mm20mm
    910mm6mm6mm22mm
    1012mm7mm6mm25mm
