Key Features:
Noise Reduction: Our stackers are equipped with advanced shock
absorbers, effectively reducing noise for a quieter operation.
Extended Battery Life: Benefit from the low voltage protection
feature, which safeguards the battery and ensures longer
operational hours.
Unmatched Stability: The four-point low center of gravity design
offers unparalleled stability, instilling confidence during
handling tasks.
Efficient and Compact: Our stackers feature a compact design that
incorporates regenerative braking for enhanced efficiency.
Additionally, the streamlined structure facilitates easy
maintenance, saving you time and effort.
Versatile Capacity: Lift and slide loads of up to 1.5 tons
effortlessly, with mast options ranging from 1.6 to 3.5 meters to
accommodate various lifting requirements.
Certified Quality: Rest assured knowing that our electric pallet
stackers are CE and ISO certified, guaranteeing compliance with
international standards.
Choose AIDA for top-notch electric pallet stackers that prioritize
quality, reliability, and performance. Contact us today to discover
the perfect solution for your lifting needs. Elevate your
operations with AIDA's expertise.
Specification
| Model | WDG10QL |
| Load capacity | 1000kg |
| Tyre size, front | φ80×70 |
| Tyre size, rear | φ210×70 |
| Lift height | 1600/2500/3000/3500mm |
| Lowered height | 90mm |
| Overall length | 1750mm |
| Fork dimensions | 1070×142×60mm |
| Distance between fork arms | 550/660mm |
| Turning radius | 1437mm |
| Groung clearance | 30mm |
| Travel speed | 3.5/4 km/h |
| Gradient,Laden/unladen | 3/10% |
| Drive motor | 0.6kw |
| Lift motor | 2kw |
| Battery | lead-acid 24V 65Ah |
