| Brand Name : | FESTO |
| Model Number : | NPQH-T-Q8-E-P10 |
| Price : | EXW USD3-5 |
| Payment Terms : | T/T, Western Union, Paypal |
| Supply Ability : | 1800 pcs per week |
| Delivery Time : | 7-10 working days |
About product
Note on operating and pilot medium:Lubricated operation possible
Corrosion resistance class CRC:3 - high corrosion stress
Note on materials: RoHS-compliant
Product Technical Data
| Size | Standard |
| Nominal size | 7 mm |
| Tubing insertion depth | 16 mm |
| Mounting position | optional |
| Design | T-shape |
| Size of pack | 10 |
| Design | Push-pull principle |
| Symbol | 00997424 |
| Certificate issuing authority | NSF C0523185 |
| Note on operating and pilot medium | Lubricated operation possible |
| Corrosion resistance class CRC | 3 - high corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Cleanroom class | Class 4 according to ISO 14644-1 |
| Product weight | 28.6 g |
| Pneumatic connection, port 1 | For tubing outer diameter of 8 mm |
| Pneumatic connection, port 2 | For tubing outside diameter of 8 mm |
| Note on materials | RoHS-compliant |
| Material housing | Brass, chemically nickel-plated |
| Guard ring material | PEI |
| Material release ring | Brass, chemically nickel-plated |
| Material tubing seal | FPM |
| Material tubing clamp component | High-alloy stainless steel |
| Thrust ring material | PEI |
Dimensions and ordering data

There are so many models.Welcome to enquiry !
|
