    Bottle Chemical Packaging Machine 50-1000ml Carton Packing Machine

    Ask Lasest Price
    Brand Name : TOM
    Model Number : ZX-01
    Certification : CE, ISO,CO
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 25 sets per month
    Delivery Time : 30 working days
    • Product Details
    • Company Profile

    Bottle Chemical Packaging Machine 50-1000ml Carton Packing Machine

    ZX-01 Fully Automtaic PLC Controlled carton packing machine For Bottle

    Major Characteristics:

    This machine is an intelligent automatic carton packaging machine, it adopts cylinder to push the bottle when the bottle come to the right position, and then adopts vacuum sucker to sucking the bottle, the bottle sucker take the bottles to the forme cartons, and then the sucker release, the loaded carton is sent to the carton sealing, it can avoid hurting the caps with this method. This machine adopts PLC and touch screen controlled with the safety device of alarming and stopping for bottle lacking. Greatly reduce the labor and labor force, it the indispensable machine of automation production line, according to different packaging requirement, can orient the products automatically. Wide application, suitable for many kinds of products.

    Main Performance parameter:

    Machine typeZX-01
    Powder supply220V/380V 50/60hz 6KW
    Suitable sizeL:200-500 W:150-400 H:100-450mm
    Speed2-12carton/min
    Width of the tape48/60mm/72mm
    Air Source6-7kg
    Dimension2000mm(L)×1200mm(W)×2000mm(H)
    Weight1400KG

    Applicable bottle type


    1, according to the user's actual production line capacity, the main machine can be designed for one box, two boxes, three boxes, or customized four boxes, etc. Capacity varies, the number of grippers varies.

    2. All actions are centrally controlled by electric control system. High integration, strong control ability, reliable operation;

    3. When the host is working, it has the function of interlocking control and protection. All actions are controlled by the programmable controller P LC, photoelectric detection and touch screen operation; When the host is short of bottles, less bottles, short of boxes, less boxes, the host does not work, when the working conditions are met, the host automatically works;

    4. All the grippers are imported cylinders of high quality, with firm grip and flexible action


    The conveyor frame in and out of the box is made of SUS304 stainless steel. The railings on both sides are adjustable and can be applied to different box types. The railings are aluminum profile outsourcing polyethylene material protection rods, and the surface is smooth without burr and will not damage the box.


    There are photoelectric sensors in all parts of the equipment to ensure that no bottles, few bottles, few boxes are not packed, and the work will be carried out after the bottles and boxes are in place



    Jiangsu Tom Group is an enterprise specializing in the production of pesticide / veterinary medicine, fertilizer and chemical intelligent equipment. The factory covers an area of 150 acres and has a construction area of 120,558 square meters. It has 710 employees, 2 doctoral students, 30 master students, and 358 undergraduates. It has obtained ISO9001 quality system. Certification, ISO14001 Environmental Management System Certification, OHSAS18001 Occupational Health and Safety System Certification, CE Certification, Jiangsu Province Specialized Specialized New "Little Giant" Enterprise, Changzhou Specialized Specialized New Small and Medium Enterprise, 125 National Utility Patents and 26 National Inventions patent. Over the past 24 years, after the hard work of Tom people, Tom Group has continued to innovate and develop, keeping pace with the times, providing generations of advanced intelligent packaging equipment for more than 3,300 pesticide / veterinary medicine, fertilizer and chemical companies, and building Industry 4.0 intelligent factories for customers; Provide automated three-dimensional warehouse; create smart factory production data acquisition and execution system (MES) for customers.
