Digital UC800 Temperature Transmitter Smart Water Pressure Sensor
with display for temperature measurement
Description: digital Smart Water Pressure Sensor with display for temperature
measurement is a kind of temperature transmitter, which is
generated by the sensor resistance effect at temperature, to
produce a differential voltage signal converted by the dedicated
processing unit, this signal via a dedicated amplifier, the range
corresponding to the signal into a standard analog or digital
signals.
2088 Temperature transmitter with display--Model UC800 is like
picture below
Technical indicators:
| Measuring media | liquid, gas |
| Measuring range | -50-300 ℃ |
| Pressure Level | 10MPa (above can be customized) |
| Accuracy class | ± 0.5 ℃ |
| Stability | ± 0.1% FS / Year |
| Protection | IP65 |
| Ambient temperature | -40 ~ 85 ℃ |
| Power supply range | 9 ~ 36VDC |
| Output signal | 4 ~ 20mA, 0-5VDC, 0-10VDC, RS485 |
| Probe material | stainless steel 304 |
Maximum power: current type ≤0.02Us (W) voltage-≤0.008Us (W)
numeric ≤0.015Us (W) Note: Us = supply voltage
Load characteristics: current-load ≤ {(Us-7) ÷ 0.02 (Us = supply
voltage)} Ω
Voltage type load ≥100kΩ
Application:
Suitable for indoor plumbing or cavities within the body
temperature measurement, non-hazardous general scene.
Features:
Wide voltage power supply, non-linear correction, high accuracy
Small size, light weight, easy to install
Lightning, cutoff frequency interference design, anti-interference
ability
Wiring reverse and overvoltage protection, current limiting
protection
Picture details
