N156HCE-G72 Innolux 15.6" 1920(RGB)×1080 400 cd/m² INDUSTRIAL LCD DISPLAY

    Buy cheap N156HCE-G72 Innolux 15.6

    Buy cheap N156HCE-G72 Innolux 15.6
    • Buy cheap N156HCE-G72 Innolux 15.6
    • Buy cheap N156HCE-G72 Innolux 15.6
    • Buy cheap N156HCE-G72 Innolux 15.6

    N156HCE-G72 Innolux 15.6" 1920(RGB)×1080 400 cd/m² INDUSTRIAL LCD DISPLAY

    Ask Lasest Price
    Brand Name : INNOLUX
    Model Number : N156HCE-G72
    Certification : ISO9001
    Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION
    Supply Ability : 100PCS
    Delivery Time : 1-2 DAYS
    • Product Details
    • Company Profile

    N156HCE-G72 Innolux 15.6" 1920(RGB)×1080 400 cd/m² INDUSTRIAL LCD DISPLAY

    Innolux N156HCE-G72 Application Features

    Basic Information :Brand NameModel Name 4 CompatibleTypeModel Alias
    N156HCE-G72a-Si TFT-LCD , LCMCMN1529
    Maximum Ratings :RoHSOperating TemperatureStorage TemperatureVibration Level
    0 ~ 50 °C-20 ~ 60 °C

    Innolux N156HCE-G72 Mechanical Features

    Screen Size :15.6"
    Pixel Features :Pixel NumberPixel FormatDot Pitch (H×V)Pixel Pitch (H×V)
    1920(RGB)×1080, FHDRGB Vertical Stripe0.05975×0.17925 mm0.17925×0.17925 mm [141PPI]
    Mechanical Size :Display Area (H×V)Bezel Opening (H×V)Overall Dimension (H×V)Overall Depth
    344.16×193.59 mm346.76×196.69 mm350.66×205.24 mm2.45/5.0 (Typ./Max.) mm
    Outline Features :Form ShapeAspect Ratio (H:V)OrientationShape Style
    Flat Rectangle16:9Landscape typeSlim (PCBA Bent, T≤3.0mm)
    Other Spec :MassPanel CoverSurface Treatment
    305/320g (Typ./Max.)-Antiglare, Hard coating (3H)
    Holes & Brackets :Without

    Innolux N156HCE-G72 Optical Features

    Basic Information :LuminanceWork ModeContrast Ratio
    400 cd/m² (Typ.)AAS, Normally Black, Transmissive1200:1 (Typ.) (Transmissive)
    Good View atViewing AngleResponse Time
    Symmetry89/89/89/89 (Typ.)(CR≥10)11/9 (Typ.)(Tr/Td) (ms)
    Dispaly Color :Color Temperature:Support ColorColor Coordinate
    6485K16.7M/1.06B (8-bit / 8-bit + FRC)X:0.313; Y:0.329
    1931 Color Gamlt :NTSC RatiosRGB CoverageAdobe RGB Coverage
    71%100%74%
    DCI-P3 CoverageRec.2020 CoverageRemarks
    74%53%sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
    White Uniformity :1.18/1.54 (Max.)(5/13 points)

    Innolux N156HCE-G72 Backlight Features

    Back-light Features:TypePositionLife(Hours)AmountShapeReplacement
    WLEDEdge light type15K(Min.)---
    Interface Features :WLED Driver StatePhysical TypeInterface Position
    With LED DriverIncluded in panel signal interface-
    WLED Driver Electrical :Input VoltageInput CurrentPower Consumption
    5.0/12.0/21.0V (Min./Typ./Max.)277/290mA (Typ./Max.)3.5W (Max.)

    Innolux N156HCE-G72 Interface Features

    Signal Electrical :Input VoltageInput CurrentPower Consumption
    3.3V (Typ.)230/250mA (Typ./Max.)0.85W (Max.)
    Interface Features :Signal TypePhysical TypeInterface Position
    eDP (2 Lanes), eDP1.2Connector
    Interface Detail :Brand NameModel NameAmountPinsPin PitchPin Configuration
    I-PEX20682-030E-021 pcs30 pins0.4 mmEDP-30P2L-020V

    FAQ:
    Q1: What's the quality of your LCD Panel?
    A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
    Q2: What is your return and refund policy?
    A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
    Q3: How long is the lead time?
    A: The lead time is about 1-3 working days after receipt of payment.
    Q4: How can I get the quotation?
    A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
