N156BGE-E42 Innolux 15.6" 1366(RGB)×768 220 cd/m² INDUSTRIAL LCD DISPLAY

N156BGE-E42 Innolux 15.6" 1366(RGB)×768 220 cd/m² INDUSTRIAL LCD DISPLAY

Ask Lasest Price
Brand Name :	INNOLUX
Model Number :	N156BGE-E42
Certification :	ISO9001
Payment Terms :	TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability :	500PCS
Delivery Time :	1-2 DAYS

Add to Cart

Product Details
Company Profile

N156BGE-E42 Innolux 15.6" 1366(RGB)×768 220 cd/m² INDUSTRIAL LCD DISPLAY

Innolux N156BGE-E42 Application Features

Basic Information :	Brand	Model 1 Compatible	Type	Model Alias
Basic Information :		N156BGE-E42	a-Si TFT-LCD , LCM	CMN15CA
Reliability :	RoHS	Operating Temperature	Storage Temperature	Vibration Resistance
Reliability :		0 ~ 50 °C	-20 ~ 60 °C

Innolux N156BGE-E42 Mechanical Features

Panel Size :	15.6 inch
Pixel Features :	Resolution	Pixel Arrangement	Dot Pitch (W×H)	Pixel Pitch (W×H)
Pixel Features :	1366(RGB)×768, WXGA	RGB Vertical Stripe	0.084×0.252 mm	0.252×0.252 mm [100PPI]
Mechanical Size :	Active Area (W×H)	Bezel Area (W×H)	Outline Dimension (W×H)	Outline Depth
Mechanical Size :	344.232×193.536 mm	347.36×196.59 mm	359.5×223.8 mm	3.3/3.6 (Typ./Max.) mm
Outline Features :	Form Style	Aspect Ratio	Orientation	Shape Style
Outline Features :	Flat Rectangle	16:9 (W : H)	Landscape type	Flat (PCBA Flat, T3.4~4.0mm)
Fixation :	Face mounting holes (8 pcs) on up, down slugs
Other Features :	Panel Cover	Weight	Surface
Other Features :	-	365/380g (Typ./Max.)	Glare (Haze 0%), Hard coating (3H)

Innolux N156BGE-E42 Optical Features

Basic Information :	Brightness	Operating Mode	Contrast Ratio
	220 cd/m² (Typ.)	TN, Normally White, Transmissive	600:1 (Typ.) (Transmissive)
	Viewing Angle(L/R/U/D)	Viewing Direction	Response Speed
	45/45/20/45 (Typ.)(CR≥10)	6 o'clock	3/7 (Typ.)(Tr/Td) (ms)
Dispaly Color :	Color Temperature	Color Amount	White color Chromaticity
Dispaly Color :	6485K	262K (6-bit)	X:0.313; Y:0.329
1931 Color Gamlt :	NTSC Ratio	sRGB Coverage	Adobe RGB Coverage
	47%	65%	49%
	DCI-P3 Coverage	Rec.2020 Coverage	Remarks
	49%	35%	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Luminance Variation :	1.25 (Max.)(5 points)

Innolux N156BGE-E42 Interface Features

Signal Electrical :	Current Input		Voltage Input			Consumption
Signal Electrical :	180/257mA (Typ./Max.)		3.3V (Typ.)			0.85W (Max.)
Interface Features :	Position	Type	Interface
Interface Features :		Connector	eDP (1 Lane)
Signal Interface :	Brand	Model	Amount	Pin Pitch	Pins	Pin Assignment
Signal Interface :	I-PEX	20455-030E-12	1 pcs	0.5 mm	30 pins	EDP-30P1L-030A

Innolux N156BGE-E42 Backlight Features

Backlight Features:	Type	Position	Shape	Amount	Life(Hours)	Replacement
Backlight Features:	WLED	Edge light type	-	-	15K(Min.)	-
Interface Features :	Position	Type	WLED Driver
Interface Features :	-	Included in panel signal interface	With LED Driver
Driver Electrical :	Current Input		Voltage Input			Consumption
Driver Electrical :	144/181/193mA (Min./Typ./Max.)		5.0/12.0/21.0V (Min./Typ./Max.)			2.40W (Max.)

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
