N101L6-L01 CMO 10.1" 1024(RGB)×600 200 cd/m² INDUSTRIAL LCD DISPLAY

    Buy cheap N101L6-L01 CMO 10.1

    Buy cheap N101L6-L01 CMO 10.1
    • Buy cheap N101L6-L01 CMO 10.1
    • Buy cheap N101L6-L01 CMO 10.1
    • Buy cheap N101L6-L01 CMO 10.1

    N101L6-L01 CMO 10.1" 1024(RGB)×600 200 cd/m² INDUSTRIAL LCD DISPLAY

    Ask Lasest Price
    Brand Name : CMO
    Model Number : N101L6-L01
    Certification : ISO9001
    Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION
    Supply Ability : 500PCS
    Delivery Time : 1-2 DAYS
    • Product Details
    • Company Profile

    N101L6-L01 CMO 10.1" 1024(RGB)×600 200 cd/m² INDUSTRIAL LCD DISPLAY

    CMO N101L6-L01 Application Details

    Basic Info :Panel BrandPanel ModelN101L6-L01 9 Compatible
    Diagonal Size10.1"Application
    Panel Typea-Si TFT-LCD , LCMModel AliasCMO1007
    Reliability :Operating Temp.0 ~ 50 °CStorage Temp.-20 ~ 60 °C

    CMO N101L6-L01 Mechanical Details

    Pixel Features :Pixel Format1024(RGB)×600 [WSVGA]Dot Pitch0.0725×0.2088 mm (H×V)
    ConfigurationRGB Vertical StripePixel Pitch0.2175×0.2088 mm (H×V) [117PPI]
    Mechanical Size :Display Area222.72×125.28 mm (H×V)Bezel Area226.34×128.1 mm (H×V)
    Outline Dim.235×143 mm (H×V)Outline Depth4.9/5.2 (Typ./Max.) mm
    Outline Features :Form FactorFlat RectangleOrientationLandscape type
    Aspect Ratio16:9 (H:V)Shape StyleWedge (PCBA Bent, T≥5.2mm)
    Holes & Brackets :Side mounting holes (4-M2) on left, right bezel
    Other Features :Weight180/190g (Typ./Max.)SurfaceAntiglare (Haze 25%), Hard coating (3H)

    CMO N101L6-L01 Optical Details

    Basic Information :Brightness200 cd/m² (Typ.)Contrast Ratio500:1 (Typ.) (Transmissive)
    Viewing Angle45/45/20/45 (Typ.)(CR≥10)Optical ModeTN, Normally White, Transmissive
    Viewing Direction6 o'clockResponse Time3/7 (Typ.)(Tr/Td) (ms)
    Color Performance :ChromaticityWx:0.313; Wy:0.329Color Numbers262K (6-bit)
    Color Temperature6485KWhite Uniformity1.25 (Max.)(5 points)
    1931 Color Gamlt :NTSC Ratio44%sRGB62% coverage
    Adobe RGB46% coverageDCI-P346% coverage
    Rec.202033% coverageRemarkssRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

    CMO N101L6-L01 Backlight Details

    Back-light Features:Lamp Shape2 stringsLamp TypeWLEDLife Time15K(Min.) (Hours)
    Replacement-Amount9S2PPositionEdge light type
    Lamp Electrical :Voltage Input26.1/28.8/30.6V (Min./Typ./Max.)Current Input20±1mA
    Consumption1.00/1.15/1.29W (Min./Typ./Max.)
    Interface Features :TypeIncluded in panel signal interfacePosition-Lamp DriverWith LED Driver
    Driver Electrical :Voltage Input5.0/12.0/20.0V (Min./Typ./Max.)Current Input-

    CMO N101L6-L01 Interface Details

    Signal Systerm :LVDS (1 ch, 6-bit)Logic Voltage-
    Signal Electrical :Voltage Input3.3V (Typ.)Current Input210/230mA (Typ./Max.)
    Interface Features :TypeConnectorPosition
    Connector Detail :BrandModelPin PitchPinsAmountConfiguration
    I-PEX20455-040E-120.5 mm40 pins1 pcsLVDS-40P1C6B-060B

    CMO N101L6-L01 Carton Details

    Package Carton :AmountNet WeightCarton Size (L×W×H)
    40 pcs / box10.4 Kgs435×350×320 mm
