46 Inch LCD Video Wall With 3.5mm 1.7mm 0.88mm Narrow bezel
Quick details:
1. BOE LG Samsung original panel on option LCD video wall in
resolution 2k 4k on option
2. Super narrow bezel of 3.5mm 1.7mm 0.88mm on option and
brightness of 500nits
3. Free combination the No. of the screen according the dispaly
area like 2*2, 3*3, 4*4,4*5, 6*6 etc.
4. Multi installation :wall mount or stand on the floor, can be
with floor standing cabinet or floor stand bracket with your own
decoration
5. Front-maintenance bracket also on option
6. Full screen dispalying and each screen displaying different
content support, also random screen combination display full screen
also support
7. 1.5M length HDMI cable, 1.5M length Lan cable, 1.8M length power
cable and software to be provided for free.
8. Player box Processor and matrix on option.
9. It is widely used in advertising, brand publishing, display
advertising and other fields.
10. Touch screen on sales, IR touch frame size can be Customized as
per request
11. Panel Size: 46"49"50"55"58"65"
12. Four installation methods : Cabinet / Floor standing / Front
maintenance / Wall mount
13. Three external connections: splitter/matrix/processor
Description:
LCD splicing screen uses LED back light, so its whole
light-emitting mode is more uniform, brightness and contrast are
more balanced. The most important thing is that it can achieve 1920
* 1080 resolution display of single screen, and can also achieve 4K
and point-to-point display at most. So we can see that the LCD
splicing screen will be clearer, and the screen will not be
dazzling. LCD splicing screen not only has certain advantages in
the display, but also has excellent stability, rarely after-sales
situation. At the same time, its panel is processed by industrial
level, so it can stand continuous power on all day, which is the
main reason why it entered the field of security monitoring and
display at the beginning.
According to the different stitching of LCD splicing screen, its
application fields mainly include security monitoring, conference,
display, big data, media, advertising and other occasions. Although
the resolution of full-color LED display is low, if it is viewed
from a distance, the impact will be much smaller, and because it
has no gap after splicing, it is widely used in advertising, brand
publishing, display advertising and other fields.
For curved video wall, the screen can also match this requirements,
we will produce floorstanding cabinet bracket in curved degree. It
also can be with touch frame to become interactive screen, we're
the one-stop supplier, provide the full solution, you just need to
tell us what you need and when you open our package, just install
them and then use it, all cables and brackets can be customized and
included.
Specificaiton:
| Specification | MG-460
| Panel Size | 46" |
| Panel brand | Original Samsung A level |
| Aspect Ratio | 16:9 |
| Visual Angle | Horizontal 178/Vertical178 |
| Brightness | 500cd/sqm |
| Bezel | 0.88 mm |
| Back light | LED backlight |
| Contract Ratio | 1200:1 |
| Resolution Ratio | 1920*1080 |
| Color Components | 16.7M |
| Response Time | 8ms |
| Power Consumption | 120W/150W |
| Standby power consumption | 10W |
| Power Supply | Input:AC110-220V-50/60Hz |
| Life of Panel | 60000Hours |
| Panel Display Area | 1209.6*680.4mm |
| Outline Dimension |
1210.48 × 681.28x118.1mm |
| Port | Input: HDMI*1,VGA*1,DVI*1,AV*2,RS-232*1,Output: AV*1,RS-232*2 |
| IR touch frame | On option |
| VGA/DVI Resolution Ratio | 640*480,800*600,1024*768,1280*1024,1600*1200,1920*1080 |
| HDMI Resolution Ratio | 480I,480P,576I,720P,1080I,1080P |
| Split Screen/PIP Mode | Two signals image or PIP |
| Splice Function | Multiscreen Splice Function(image processing Function) |
| Carton Packing | 2pc/carton, carton size: 135*34*81cm, G.W.:58kg |
| Wooden box packing | 7pc/wooden box, wooden box size:140*128*98cm, G.W.:281kg |
| Bracket carton packing(for 7pc system) | 146*34*25cm, G.W.:33kg |
Application:
In addition to the public security and traffic police and other
industries that often use monitoring and execution, some schools,
hospitals, enterprises and even families and other units will use
monitoring equipment. If the number of monitoring is large, the
display splicing screen can be used to meet the display
requirements and Exhibition shows, shopping malls, stores, etc
