    Multifunction 250um Label Printing Machine With ASC Driver Die Cutter

    Ask Lasest Price
    Brand Name : EcooGraphix
    Model Number : Ecoo-VP320
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 300SET
    Delivery Time : 30 DAYS
    • Product Details
    • Company Profile

    Multifunction 250um Label Printing Machine With ASC Driver Die Cutter

    Digital Label Printer 1200x2400 dpi LED Chips with ASC Driver

    Ecoo-VP320


    Product Description

    • Digital Label Printing Machine

    • Multifunction, High Quality, High Efficiency

      The best assistant is for labeling printing.

    • 1200*2400dpi Self-scanning LED chips with ASC Driver.

    • PhaserMatch 5 color management system was nested to printing software with media management system.

    • Very low temperature EA environmental toner powder without coating before and after printing.

    • IRecT is possible to correct images in ultra high-precision of up to 2400dpi.

    • The newly developed induction heating fuser incorporates a thin, non-magnetic metal.

    • Largest label up to 320mm * 1200mm, can use most of media without costing.

    • The diameter of unwinder 450mm which can hold 1000m media roll.

    • Stable tension control system can avoid media to wrinkle and Stretch, feeding more stable.

    • High quality printing with 14592 LEDS while the ASIC driver allows precise control of there LED Chips.

    • 1200*2400dpi high quality image extreme fine digital screening technology.

    • The diameter of rewinder 450mm which feeding well and stablely.

    • Temperature control system can control the image outputting is always 28degree.


    Parameter :

    Print Speed:Up to 7.26m per minute
    Print Technology:4 color (CMYK) LED technology
    Print Processor:933Hz, 2G
    Data Port:Standard : 10BASE -T/100BASE-TX. USB2.0
    Options: Internate 1000BASE-T, IEEE1284-B
    Media Width:Min. 140mm Max. 330mm
    Print Width:Min. 130mm Max. 300mm
    Pint Label Length:Up to 432mm, can get 1230mm under long label mode
    Media Type:60-250um
    Paper: Paper, High glossy paper, matt paper
    Film: PET, PP, PE, GHS
    Other: Fabric, all of media was tested in special enviroment, not tested media possible can't be used
    Resolution:1200*2400dpi
    Toner Capacity:CMY-25000 sheets (A4, 5% coverage )
    K-26000 sheets (A4, 6% coverage )
    Refer to fthe ISO/IEC guide19798
    Drum Capacity:CMYK-70000 sheets (print runs according to the operating cycle, medium side and the direction to change.
    Unwinder & Rewinder:Max. roll media diameter: 450mm
    Roll media core dismeter: 76.2mm
    Max. weight roll media: 47.2kgs
    Automatic expandable pressure system connect meida table.
    Media precessing system (static eliminate)
    Printing cooling system (options)
    Wed guide system (options)
    Size (L×W×H)1400mm×750mm×1600mm
    Operation space:
    2500mm×1850mm×1600mm
    Weight:423kgs
    Operation Environment:Temperature: 20-23
    Humidity: 45-55% relative humidity
    Power Supply:110-127V AC 50-60Hz @3800W
    220-240V AC 50-60Hz @3800W
    Power Consumption:(AC220-240V) Sleep: 25W
    Waiting: 135W
    Running: 1200W

    Remark: 1.Published performance results based on laborattory, individual results may vary.

    2. The products was designed operated base on using vorey genunine consumables, certified media and parts, please contact Vorey get registered media list.

    3. Vorey reserves the right to change specification of product without prior to notice, trademark are the property of their respective manufacturer.



    Auto web guide tension system:

    1 For tension adjustment of all media

    2 Auto calculate the length of feeding

    3 Ultrasonic detect edge of media to avoid media loading twisty

    4 Avoid printing image to stretched and twisted

    5 Increase the lifespam of engine


    Consumables:

    Toner K: print 26 sheets A4 with 5% coverage

    Toner CMY: print 18.5K sheets A4 with 5% coverage

    Drum: 100K sheets A4

    Waste box: 300k sheets A4

    Transfer cleaner: 200k sheets A4

    Transfer roller: 200k sheets A4

    Developer CMYK: 480k sheets A4

    Developer house: 480k sheets A4

    Fuser: 480k sheets A4

    Transfer belt Assy: 480k sheets A4
