    Fabric Surface Demountable Mobile Foldable Partition Wall For Church

    Ask Lasest Price
    Brand Name : EBUNGE
    Model Number : Type 65 foldable partition wall
    Certification : ISO 9001
    Price : $82-88 per square meter
    Payment Terms : T/T, MoneyGram
    Supply Ability : 50000 square meters per month
    Delivery Time : 7-15 days
    • Product Details
    • Company Profile

    Fabric Surface Demountable Mobile Foldable Partition Wall For Church

    Fabric Surface Demountable Mobile Foldable Partition Wall for Church


    How to maintain the foldable partition walls?


    1. Clean & lightly lubricate all track running surfaces.


    2. Check trolleys for any signs of abnormal wear or breakage. Replace as needed.


    3. Check foldable partition wall panels "out of plumb" (indicating loose trolley bolts). Correct by adjusting to plumb and tightening trolley nuts.


    4. Check any exposed bolts on foldable partition wall panel's vertical edges and tighten if required.


    5. Check for foldable partition wall track misalignment at all joints & intersections and adjust if needed.


    6. Check lever closure and adjust as needed.


    7. Check and make sure all top & bottom seals are functioning properly.


    8. Operate pass door and adjust as needed.


    9. Check for torn vinyl / fabric and repair or replace as needed.


    10. Contact with us if the problem can’t be solved by the owner.


    Technical Information


    SeriesBG65BG85BG100
    Panel suspensionTop hung onlyTop hung onlyTop hung only
    Track systemSingle or twin pointSingle or twin pointSingle or twin point
    Panel thickness65mm80mm / 85mm100mm
    Panel heightUp to 4000mmUp to 6000mmUp to 18000mm
    Max height4000mm6000mm18000mm
    Panel width600-1230mm600-1230mm600-1230mm
    Frame constructionAluminum frameAluminum frameAluminum frame
    Face material9mm9mm / 12mm12mm
    Fire safetyOptional Class I or OOptional Class I or OOptional Class I or O
    Vertical profilesAluminum anodised with sealing profilesAluminum anodised with sealing profilesAluminum anodised with sealing profiles
    Retractable sealsAluminum black with
    double rubber seals
    Aluminum black with double rubber sealsAluminum black with double rubber seals
    Operation of sealsManual, with supplied
    operating handle
    Manual, with supplied operating handleManual, with supplied operating handle
    LockingOptional lock to pass doorsOptional lock to pass doorsOptional lock to pass doors
    Pass doorsSingle open in panel or
    double open in two panel
    Single open in panel or double open in two panelSingle open in panel or double open in two panel
    Sound insulation20-32dB Rw28-36dB Rw32-50dB Rw
    WeightApprox 22-35kg/sq MApprox 25-40kg/sq MApprox30-48kg/sq M
    Finish MaterialPlywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)

    Foldable partition wall solution


    PROBLEMPOSSIBLE CAUSEPROBABLE SOLUTION
    Panels Hanging out of plumb.1. Loose or broken trolleys. 2. Broken Trolley Support Beam.1. Tighten loose carries to return panel to plumb. 2. Replace any broken carriers or support beam.
    Panels sticking or hard to move.1. Dirt in the track. 2.less lubricate oil.3. Misaligned track joints. 3. Trolley Broken.1. Clean track. 2.Spread lubricate oil on the track.2. Align joints. 3. Replace trolley.
    Abnormal noise during movement.1. Broken trolley 2. Misaligned track joints1. Replace trolley 2. Align joints
    Top and bottom seal inoperative1.Cranking mechanism stripped / broken link to mechanism 2.top seal stuck by the trolley support beam

    1. Straighten or replace seal. /. Replace

    2.Adjust the size of the hole located on the top seal

    Pass doors not latching1. Strike plate out of adjustment. 2.door jamb over pressure compressed.1. Readjust strike plate. 2. Reverse previous step to re position the pass door,and not compress the LCP to much pressure
    Broken or worn trolleys

    1. Bad track joints.

    2. 2. Abusive handling at "T" or "L" intersections.

    1. Realign track joints & replace trolleys.

    2. Replace trolleys and retrain personnel.

    Lever closure jamb not extending or operates difficult.1. Internal mechanism stripped. 2. Limit cables or chains tangled. 3. Tension bolts too tight.1. Replace mechanism. 2. Adjust limit chains. 3. Adjust tension bolts on mechanism.
