Medical Needle Tubing Mould for Different Size in Plastic Injection
Molding with Multi Cavity
Quick Details
Place of Origin: Dongguan, China
Brand Name:ABS
Model Number: custom
Shaping Mode: Plastic Injection Mould
Product Material: Steel, Plastic, Plastic ABS,PC,PE,PP,PMMA,PA,PVC
Product: Household Product, plastic injection syringe mold
Mould material: 718H ,S136,NAK80,P20,P20H
Product Name: medical equipment plastic syringe injection mold
Mould Base standards: DME, HASCO, MISUMI, LKM, etc
Keyword: plastic injection syringe mold
Surface Treatment: Satin,texture,polish.....
Machines: CNC Millings, Grinding Machine, EDM, etc
Drawing Format: Dwg .step .igs, solidwork, etc
Runner: Cold/hot runner
Supply Ability
Supply Ability: 50 Set/Sets per Month
Packaging & Delivery
Packaging Details
We pack our goods in wooden case or as per required. After the
final sample confirmed, then the mold will be sent to port and
waiting for chipping.
Product Description:
Product Name | Medical Needle Tubing Mould for Different Size in Plastic Injection
Molding with Multi Cavity |
Mold Shaping | Plastic Injection Molding |
Mold Base | LKM, HASCO, DME, etc. |
Mold Steel | ASSAB8418, S136, 718H, 738H, etc. |
Mold Cavity | 48 Cavities |
Tolerance | +/0.002mm |
Finish | Polish, Silk Screen, Painting, etc. |
Sprue Gate | Hot runner, Cold runner, Tunnel gate, Pin point gate, sub-gate,
etc. |
Drawing Format | STEP/STP/IGS/CAD/PDF/DWG/STL,etc. |
Product Resin | PC, ABS, PP, POM, PBT, NYLON, PMMA, TPE, TPU, SAN, etc. |
Mold Life | 100K - 1.5M |
T0 Lead Time | 4 - 7 weeks |
Transportation | By sea, by air, by land or train as your instruction |
Package | YF mold standard package based on different transportation way or
as your instruction |
Ship Condition | Ex work, FOB or to be negotiated |
Certificate | ISO 9001:2015 |
OEM/ODM | YES |
Working Flow Chart
RFQ
Purchase Order
Mold Flow Analysis & DFM analysis
Mold design
Design validation
Tolerance analysis
Mold making(full dimension measurement)
Mold trial(free samples, FAI, CPK)
4 hours running before mold delivery
Main QC Procedure:
1. Review on the Mold Specification Sheet
2. Steel Hardness Inspection
3. Electrodes Inspection
4. Cavity and Core Dimension Inspection
5. Pre-assembly Inspection
6. Trial Repor and Plastis Parts Dimension Inspection
7. Final Mould Check (Before Shipment)
8. Package Inspection
Delivery and Package:
Wooden Package for Mould
Carton Package for Plastic Parts
Plastic Samples Deliveried by DHL, FEDEX, TNT
Mould Deliveried by Plain, Ship or Train
