    1.4L Pesticide Laboratory Grinding Mill 304ss Chemical Liquid Bead Mill Process

    Ask Lasest Price
    Brand Name : AllWin
    Model Number : MINI1.4
    Certification : ISO9001
    Price : USD2000--USD8000/set
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 30sets /month
    Delivery Time : 20-30 Working days
    • Product Details
    • Company Profile

    1.4L Pesticide Laboratory Grinding Mill 304ss Chemical Liquid Bead Mill Process

    2.2kW 1.4L Laboratory Bead Mill For Paint Coating Pesticide Chemical Liquid

    This laboratory Bead Mill is widely used in coating and paint, pigment, pesticide and agro-chemical industry, Pigment and dyestuffs, Printing inks, Gravure inks, food and food processing. have model from 0.6-2.L for meet different needs. If need we could offer the 2sets dispersing systems: both Disepersing disk and pegs.


    The Main Technical Parameter:

    NOItemsMIN1.4Note
    1

    Effective Volume(L)

    1.4L
    2Main power4 kWEX-proof 380V 50Hz
    3

    Cooling water consumption

    (L/min)

    1 m3/hthe cooling water lower than 10℃. Is better
    4Mechanical seal

    Integral single end mechanical seal reinforced lubrication system

    5BearingNSK bearing
    6Feed pumpG1/2” ARO diaphragm pump
    7Outer Chamber304 stainless steel
    8Inner chambersilicon carbide ceramics
    9Dispersing diskwear resistant alloy steel
    10Discharging way304 stainless steel, Screen ring static discharge
    11Feeding and discharging end covers on the chamber304 stainless steel
    12ApplianceDelixi
    13Frequency converterwith
    • No explosion proof, away from the scene

    The After Sales Service:

    1. Video instructions for installation and commissioning, if need, we will arrange engineer to your factory.

    2. 12-24H feedback any customers questions, firstly offer the video help you solving, if need, arrange maintenance engineer for you.

    The package and shipping: Be covered with anti-abrasion film and then packed in wooden boxes, then sea shipping by FCL or LCL.

    Also offered the related products: Dispersing machine & the Zirconical beads, This 2 products are much important for the Bead mills, this materials is pre-dispersing well, It's better for grinding with bead mill after pre-dispersing well. Also the zirconial beads (grinding beads with different size for meeting different finally fineness.

    Note:
    1.We will recommend the suitable bead mills according to your information and demand, such as industry, fineness, temperature, viscosity,production capacity etcs.
    2. The Materials of inner chamber and Dispersing disks can be chosed according to your different grinding materials and industries.
    3. The control system will be matching of different demand, such as PLC or traditional Button type.

    If need more detailed information and Price, please don't hesitate contact us, Also Warmly welcome to visit us.
