    OTDR Meter Tester 1625/1310/1550

    Ask Lasest Price
    Brand Name : SUNWISE
    Model Number : OTDR-A
    Certification : ISO9001,RoHS,CE RoHS FCC
    • Product Details
    • Company Profile

    OTDR Meter Tester 1625/1310/1550

    ♥ Large touch screen + shortcut keys, easy to operate.

    Large capacity polymer lithium battery with superlong working hours.

    Intellegient tesing, simple use and powerful function.

    Media of memory card+SD card with superlarge storage capacity of traces.

    Able to meet FTTX testing needs.

    Several wavelength can be choosen.

    Solid casing design,dustproof and shockproof.

    Wavelength(nm)850/13001310/15501310/1490/15501625
    Dynamic Range(dB)²21/1932/3032/30/3034^4 36^5
    Push Width(ns)5 20 40 80 160 320 640 12605 10 20 40 80 160 320 640 1280 2560 5120 1024 20480
    Event Blind Zone(m)³10≤1.8
    Attenuation blind zone (m)³20≤10
    Display5.6" LCD touch screen
    Linearilty(dB)±0.05
    Loss threshold(dB)0.05
    Loss resolution ration(dB)0.01
    Sampling resolution ration(m)0.125 to 8
    Sampling point32 K
    Distance Uncertainty (m)±(1 m+5×10×distance+sampling interval)
    Distance Scope(km)0.3 to 180
    Typical real-time refreshing duration(s)0.2
    Memory capacity of traceSD Card(4G) ≥1000 pcs
    Duration of measurementDefined by users: 5s 10s 15s 30s or 1min 2min 3min

    Dimension(H*W*D)150*235*66mm
    Weight1.5 KG
    TemperatureRunning temperature: -10℃ to +50
    Memory temperature: -40℃ to +70℃
    Relative humidity0% to 95%(non condensation)
    Power supplyLithium battery: continuing working duration ≥8 hrs

    Optical interfaceFC/UPC (PC and are selectable)
    Data interfaceUSB interface and SD card interface

    OTDR Visible Failure Orientation VFL

    Wavelength650 nm
    Output power(dBm)≥ -3
    Maximum testing distance3 KM

    Remarks:

    The technical specification describes the ensured performance of the instrument when using typical PC model connector to measure. Without considering the uncertainty caused by optical fiber

    refraactivity.

    Dynamic range is the data measured under the condition of the maximum pulse width and 3

    minutes of average time. Dynamic range is the data measured under the condition of 180Km/2480

    ns/3min.

    Measuring conditions of blind zone : reflection event is within 4 Km, reflection strength < -45dB.

    Measured by the minimum pulse width.

    Dynamic range measured when there is filter.

    Dynamic range measured when there is no filter.
