    TP304L Rectangular Steel Tubing

    Ask Lasest Price
    Brand Name : xinzheng
    Model Number : Sanitary Tube
    Certification : ISO,SGS,ISO & SGS,ISO/CE/SGS
    Price : 1-2USD / kg
    Payment Terms : L/C, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 4000 MT PER week
    Delivery Time : 5-25 Days
    • Product Details
    • Company Profile

    TP304L Rectangular Steel Tubing

    EN JIS 304 /316 Mirror Finished Or Polished ,Brushed Stainless Steel Rectangular Seamless Tube For Fabrication

    EN JIS 304 /316 Mirror Finished Or Polished ,Brushed Stainless Steel Rectangular Seamless Tube For Fabrication overview


    304/304L and 316/316L. Either grade is ideal for all structural applications, general fabrication, manufacturing and repairs. Steel rectangular tubing is widely used in industrial maintenance, agricultural implements, transportation equipment, etc. Its box-shape configuration makes it strong, rigid and durable. This steel shape is easy to weld, cut, form and machine with the proper equipment and knowledge. At Stainless Tubular, we can customize the ideal stainless steel rectangular tubing for your unique application. We have the capabilities to create the specific rectangular tubing you need


    EN JIS 304 /316 Mirror Finished Or Polished ,Brushed Stainless Steel Rectangular Seamless Tube For Fabrication Specification and Dimension Ranges


    Size range:
    1. Square tubes:
    H10mm xW10mm to H600mm x W600mm T.:0.3mm-40mm L:max12000mm

    2. Rectangular tubes:
    H10mm x W20mm to H600mm x W800mm T.:0.3mm-40mm L:max12000mm


    Square & Rectangular Steel Pipe Size Chart

    Square Hollow Section

    Rectangular Hollow Section

    Thickness

    10*10 20*20 25*25 30*30

    10*20 20*40 30*40

    1.2-3.0

    40*40 50*50

    30*50 25*50 30*60 40*60

    1.2-4.75

    60*60

    50*70 40*80

    1.2-5.75

    70*70 80*80 75*75 90*90 100*100

    60*80 50*80 100*40 120*80

    1.5-5.75

    120*120 140*140 150*150

    160*80 100*150 140*80 100*180 200*100

    2.5-10.0

    160*160 180*180 200*200

    200*150 250*150

    3.5-12.0

    250*250 300*300 400*400 450*450 350*350

    250*200 300*200 350*200 350*250 450*250 400*300 500*200

    4.5-15.75

    400*400 500*500 550*550 600*600

    400*350 400*250 500*250 500*300 400*600

    5.0-20.0


    other Stainless steel Tubing Dimension ranges :


    Product Name

    Executive Standard

    Dimension

    Steel Code / Steel Grade

    Industrial Pipes

    ASTM A312, A358, A778, JIS G3459

    OD: 1/4"~40"

    TP304, TP304L, TP316L, SUS304TP

    WT: SCH5S~SCH80S

    Tubes for Boiler and Heat-Exchanger, General Service Tubing

    ASTM A249, A269, JIS G3463

    OD: 15.9~139.8mm

    TP304, TP304L, TP316L, SUS304TB

    WT: 1.6~5.0mm

    Mechanical and Structural Tubes

    ASTM A554, JIS G3446

    OD: 7.9~152.4mm

    MT304, MT304L, MT316L, MT430 Grade 201, 202 as per mill's STD SUS304

    WT: 0.5~6.5mm

    Square Tubes

    ASTM A554

    OD: 12.7x12.7~150x150mm

    MT304, MT304L, MT316L, MT430 Grade 201, 202 as per mill's STD

    WT: 0.7~6.5mm

    Rectangular Tubes

    ASTM A554

    OD: 10x20~100x200mm

    MT304, MT304L, MT316L, MT430 Grade 201, 202 as per mill's STD

    WT: 0.7~6.5mm

    Sanitary Tubing

    ASTM A270

    OD: 25.4~165.2mm

    TP304, TP304L, TP316L, SUS304TBS

    JIS G3447

    WT: 0.8~3.05mm

    Large Gauge Pipes for Ordinary Piping

    JIS G3448

    OD: 15.88~318.5mm

    SUS304TPD

    WT: 0.8~3.0mm

    Large Diameter Pipes

    JIS G3468

    OD: 14"~40"

    SUS304TPY

    WT: SCH5S~SCH40S


    EN JIS 304 /316 Mirror Finished Or Polished ,Brushed Stainless Steel Rectangular Seamless Tube For Fabrication Application


    Typcially use for fabrication and tooling , construction , building material ,ornamental material

    UNS S30403 304L Stainless Steel Or Nickel Alloy Seamless Pipe / Tube In Form Of Round ,Square For Aerospace Package










    FAQ


    Q: Would you provide samples For free?

    A: Yes . with on stock specification We provide samples For Free . Freight charge collect

    Q: What information should i provide to source for the right products ?

    A: Material grade, width, thickness, coating and Purchase quantity , Expected lead time ,etc


    Q: What are the shipping ports?

    A: Under normal circumstances, we ship from Shanghai, Tianjin, Qingdao, Ningbo ports, you

    can choose other ports according to your needs.


    Q: About product prices?

    A: Prices vary from period to period due to cyclical changes in the price of raw materials.


    Q: How long does your delivery time take?

    A: In general, our delivery time is within 5-45 days, and may be delayed if the demand is extremely

    large or special circumstances occur.


    Q: Can I visit your location?

    A: Of course, we welcome customers from all over the world to visit our factory. However, some

    of the plants are not open to the public.


    Q: Does the product have quality inspection before loading?

    A: Of course, all our products are strictly tested for quality before packaging, and unqualified

    products will be destroyed.


    Q: How to pack the products?

    A: The inner layer has a waterproof paper outer layer with iron packaging and is fixed with a fumigation

    wooden pallet. It can effectively protect products from corrosion during ocean transportation.


    Q: What is your working time?

    A: In general, our online service time is Beijing time: 8:00-22:00, after 22:00,

    we will reply to your inquiry during the next working day.
