    Schedule 80 A53 Carbon Steel Sheets Seamless Pipe SMLS

    Ask Lasest Price
    Brand Name : xinzheng
    Model Number : Inconel 8255
    Certification : ISO, EN, MTC
    Price : 10USD ---16 USD / kg
    Payment Terms : L/C, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 4000 MT PER week
    Delivery Time : 5-25 Days
    • Product Details
    • Company Profile

    Schedule 80 A53 Carbon Steel Sheets Seamless Pipe SMLS

    ASTM A53 Grade B Schedule 80 Cold Drawn Carbon Steel Seamless Pipe

    ASTM A53 Grade B Schedule 80 Cold Drawn Carbon Steel Seamless Pipe overview

    ASTM A53 (ASME SA53) carbon steel pipe is a specification that covers seamless and welded black and hot-dipped galvanized steel pipe in NPS 1/8" to NPS 26. SA 53 Pipe is intended for pressure and mechanical applications and is also acceptable for ordinary uses in steam, water, gas, and air lines.

    ASTM A53 Grade B Schedule 80 Cold Drawn Carbon Steel Seamless Pipe Specification and Dimension Rranges

    ASTM A53 Grade B Pipe Specification

    ASTM A53 Gr.B Pipe StandardsASTM, ASME and API
    SA53 Pipe UNS DesignationUNS K03005
    Pipe Size1/2” NB to 36” NB
    Pipe Thickness3-12mm
    Pipe SchedulesSCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules
    Pipe ToleranceCold drawn pipe: +/-0.1mm
    Cold rolled pipe: +/-0.05mm
    TechniqueCold rolled and Cold drawn Pipe
    Pipe TypeSeamless / ERW / Welded / Fabricated Pipe
    CS ASTM A53 GrB Pipe FormRound, Hydraulic Pipe Etc
    Pipe LengthMin 3 Meters, Max18 Meters, or according to customer’s requirement
    Carbon Steel ASTM A53 Gr B Pipe EndPlain End, Beveled End, Treaded
    Specialized inLarge Diameter Carbon Steel Pipe ASTM A53 Grade B

    Description :

    1. Commodity Name: Carbon Seamless steel pipe
    2. Standard: API, GB, ASTM, ASME, DIN..
    3. Quality Grade:10#,20#, A106 B, A53B, API 5L B,Q235, Q345,SA179, ST37, ST52,etc.
    4. Dimension: OD:1/2"-24"
      WT:2.5-80mm, SCH10~SCH40~XXL
      Length: up to 18 metres
    5. Technique: Hot Rolled/ Cold Rolled/ Cold Drawn carbon steel pipe
    6. Application:
      Carbon seamless steel pipes are widely used in gas,water and oil,
      Transportation; constructions; Bridge, highway, windows of model steel door;
      Building materials; fences; heating factories Fluid pipe, conduit pipe,scaffolding pipe .etc.
    7. Payment Terms:L/C,T/T
    8. Packing and shipment
      Packaged in bundles, as per customers requirements, it can also be packaged as beveled ends,
      Typed marking, black painting, plastic caps protection,blue plastic bags.waterproof cloth, steel
      strips ,Wooden box.
    9. For 20 ft container the max length is 5.85 m,For 40 ft container the max length is 12m,


    Dimension Range :


    ASTM / ASME
    Product NameExecutive StandardDimension (mm)Steel Code / Steel Grade
    Black and Hot-Dipped Zinc-Coated Seamless Steel PipesASTM A53Ø10.3~1200 x WT1.0~150Gr.A, Gr.B, Gr.C
    Seamless Carbon Steel Pipes for High Temperature ServiceASTM A106Ø10.3~1200 x WT1.0~150Gr.B, Gr.C
    Seamless Cold-Drawn Low-Carbon Steel Heat-Exchanger and Condenser TubesASTM A179Ø10.3~426 x WT1.0~36Low Carbon Steel
    Seamless Carbon Steel Boiler Tubes for High PressureASTM A192Ø10.3~426 x WT1.0~36Low Carbon Steel
    Seamless Cold-Drawn Intermediate Alloy Steel Heat-Exchanger and Condenser TubesASTM A199Ø10.3~426 x 1.0~36T5, T22
    Seamless Medium-Carbon Steel Boiler and Superheater TubesASTM A210Ø10.3~426 x WT1.0~36A1, C
    Seamless Ferritic and Austenitic Alloy Steel Boiler, Superheater and Heat-Exchanger TubesASTM A213Ø10.3~426 x WT1.0~36T5, T9, T11, T12, T22, T91
    Seamless Carbon and Alloy Steel for Mechanical TubingASTM A333Ø1/4"~42" x WT SCH20~XXSGr.1, Gr.3, Gr.6
    Seamless and Welded Carbon Steel Pipes and Alloy Steel Pipes for Low Temperature UseASTM A334Ø1/4"~4" x WT SCH20~SCH80Gr.1, Gr.6
    Seamless Cold-Drawn Carbon Steel Feedwater Heater TubesASTM A556Ø10.3~426 x WT1.0~36A2, B2
    DIN
    Product NameExecutive StandardDimension (mm)Steel Code / Steel Grade
    Seamless Steel Tubes for Elevated TemperatureDIN 17175Ø10~762 x WT1.0~120St35.8, St45.8, 10CrMo910, 15Mo3, 13CrMo44, STPL340, STB410, STB510, WB36
    Seamless Steel TubesDIN 1629 / DIN 2391Ø13.5~762 x WT1.8~120St37.0, St44.0, St52.0, St52.3
    Seamless Steel TubesDIN 2440Ø13.5~165.1 x WT1.8~4.85St33.2
    Seamless Steel Pipes for Structural PurposeDIN 2393Ø16~426 x WT1.0~36RSt34-2, RSt37-2, RSt44-2, St52
    BS
    Product NameExecutive StandardDimension (mm)Steel Code / Steel Grade
    Seamless Steel Tubes for Machine StructureBS 970Ø10~762 x WT1.0~120Carbon Steel
    Seamless Steel Tubes for Boiler and Heat ExchangersBS 3059Ø10~762 x WT1.0~120360, 410, 440, 460, 490

    ASTM A106 grade B schedule 40 cold drawn carbon steel seamless pipe for of fluids and gasses pipe Application


    For the construction sites and underground transportation, the steel pipe is used widely.

    For the extraction of the ground water, the ASTM A53 pipes are also used widely. Drawing water from the ground, steel pipes are required and the ASTM A53 is much suitable to draw the water from the ground.


    For the processing of machinery parts, steel pipes are required. You can process bearing sets and machinery parts with the ASTM A53 pipes.


    ASTM A53 pipes are also widely for the electric application. F


    or the gas transmission and connecting the electric lines and water power generation fluid lines, the ASTM A53 pipelines are used.


    This steel pipe is also used in the wind power plant. Power plants where the zinc coated steel pipes are requires, ASTM A53 steel pipes are used there..


    HASTELLOY Alloy B2, B3 UNS N010665, Super Alloy SEAMLESS PIPE Package




    FAQ

    Q: Would you provide samples For free?

    A: Yes . with on stock specification We provide samples For Free . Freight charge collect

    Q: What information should i provide to source for the right products ?
    A: Material grade, width, thickness, coating and Purchase quantity , Expected lead time ,etc
    Q: What are the shipping ports?
    A: Under normal circumstances, we ship from Shanghai, Tianjin, Qingdao, Ningbo ports, you
    can choose other ports according to your needs.
    Q: About product prices?
    A: Prices vary from period to period due to cyclical changes in the price of raw materials.
    Q: How long does your delivery time take?
    A: In general, our delivery time is within 5-45 days, and may be delayed if the demand is extremely
    large or special circumstances occur.
    Q: Can I visit your location?
    A: Of course, we welcome customers from all over the world to visit our factory. However, some
    of the plants are not open to the public.
    Q: Does the product have quality inspection before loading?
    A: Of course, all our products are strictly tested for quality before packaging, and unqualified
    products will be destroyed.
    Q: How to pack the products?
    A: The inner layer has a waterproof paper outer layer with iron packaging and is fixed with a fumigation
    wooden pallet. It can effectively protect products from corrosion during ocean transportation.
    Q: What is your working time?
    A: In general, our online service time is Beijing time: 8:00-22:00, after 22:00,
    we will reply to your inquiry during the next working day.

    equivalent grades

    ASTM A106 Grade B Pipe Equivalent

    Type
    Former
    New
    Execution
    Standard
    Material
    Standard
    Material
    Seamless
    ASTM A106
    GRADE B
    EN 10216-2
    P265GH
    Seamless
    ASTM A333
    GRADE 6
    EN 10216-4
    P265NL
    Welded
    API 5L
    Grade B
    EN 10208-2
    L245NB
    Welded
    API 5L
    Grade X52
    EN 10208-2
    L360NB
    Seamless
    API 5L
    Grade B
    EN 10208-2
    L245NB
    Seamless
    API 5L
    Grade X52
    EN 10208-2
    L360NB
    ASTM A106 Grade B Pipe TypesOut diameterWall thicknessLength
    ASTM A106 Grade B Seamless Pipe (Custom Sizes)1/2" NPS - 60" NPSSCH 5 / SCH 10 / SCH 40 / SCH 80 / SCH 160Custom
    ASTM A106 Grade B Welded Pipe (in Stock + Custom Sizes)1/2" NPS - 24" NPSAs per requirementCustom
    ASTM A106 Grade B ERW Pipe (Custom Sizes)1/2" NPS - 24" NPSAs per requirementCustom
    ASTM A106 Grade B SAW Pipe16" NPS - 100" NPSAs per requirementCustom
