    Programmable Electrical Appliance Hydraulic Pressure Test Equipment

    Ask Lasest Price
    Brand Name : Sinuo
    Model Number : SN1125-42Mpa
    Certification : Calibration Certificate (Cost Additional)
    Price : Negotiable
    Payment Terms : T/T, L/C, Western Union, MoneyGram
    Supply Ability : 10 Sets Per Month
    Delivery Time : 30 Days
    • Product Details
    • Company Profile

    Programmable Electrical Appliance Hydraulic Pressure Test Equipment


    IEC 60335 Comprehensive Hydraulic Pressure Test System


    Product information:

    This hydraulic pressure test system can match many standard testing requirements, such as:

    IEC 60335-2-5 cl.22.101 1.2 MPa or higher

    IEC 60335-2-7 cl.22.101 2.0 MPa or higher

    IEC 60335-2-21/35 22.47 twice the rated pressure (1.4MPa common from 0.6MPa inlet pressure, 2MPa for open water heater), 22.103 0.1MPa from rated of PRV

    IEC 60335-2-24 cl.22.7, etc.


    Technical parameters


    Pressure range

    0.5-32Mpa or 42Mpa

    (stepless adjustable, can be customized)

    Test mediumClean liquid water
    Test station1 station (can be customized)Allowable medium temperatureRT+5°C-80℃ (can be customized)
    Power sourceGas-liquid booster pumpDrive air pressure0.2-0.8Mpa
    Pneumatic duplexUFRL04Outlet flow0.5L/min
    High pressure pipe jointStainless steel tube, ferruleSolenoid valveSanlixin
    Clean water tankStainless steelElectronically controlled proportional valveSMC
    Control methodComputerHigh pressure gaugeKEMAI
    Max. pressure test32MpaComputerAdvantech Industrial Computer
    Chamber appearanceQ235 spray treatment

    The typical test procedures equipped are:

    ① Constant speed boost-blasting;
    ② Constant speed boost-hold pressure-blasting;
    ③ Constant speed boost-pressure hold-pressure relief;
    ④ Constant speed boost-pressure hold-constant speed boost-pressure hold-until blasting (incremental boost).



    Control features:

    The software is written by force control configuration software or LABVIEW (computer control)

    Realize the computer control function, operator can freely set the water filling and exhaust time, the pressure holding time, the inflation cleaning time, and the test pressure. During the experiment, operator can arbitrarily set a single or multi-stage pressure holding test. The speed can be kept constant, stepless adjustment can be realized, test data and curve parameters can be displayed in real time, test results can be automatically saved, and test reports can be printed at will. (computer control).
