    Warehouses Q235 10T Electric Transfer Cart Material Handling

    Ask Lasest Price
    Brand Name : BEFANBY
    Model Number : KPD
    Certification : CE,SGS,ISO9001
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1000 set/sets per year
    Delivery Time : 40-50 days as usual delivery,30-40days for urgent delivery
    • Product Details
    • Company Profile

    Warehouses Q235 10T Electric Transfer Cart Material Handling

    10T Metal Plant Use Electric Rail Transfer Wagon On Tracks

    1. Product Introduce

    flat carts power supply system custom manufacture flat cars


    BEFANBY custom manufacture 10T Metal Plant Use Electric Rail Transfer Wagon On Tracks is powered by low voltage electricity from rails, the series of 50ton and 100t transfer carts for steel iron handling is one of the most convenient material handling equipment and it generally can be widely used in the industry field and so on. Of course,compared other transfer cart,it main features as it follows,its rails is isulated with the ground, and its wheels are isulated with the ground, so doesn't others.it is the advantage that the electric flat car factory manufacturer material handling equipment used in warehouses have, why we design is that its convenient (only rails needed) and its simple operation.



    About BEFANBY, Our company have professional team and utilize more advanced technique to design and develope it , and it has been a long year to manufacture it attentively. Simutaneously, it will be more easy and flexible.Simple structure and low cost make it popular for workshop transportation.

    f

    Please contact us if you's like to learn more details and get the quotation.


    BEFANBY have over 16 years' experience in the material handling fields.

    Warehouses Q235 10T Electric Transfer Cart Material HandlingWarehouses Q235 10T Electric Transfer Cart Material Handling


    2. Application

    The Rail Transfer Wagon Is Suitable For Various Industries, Steel Mills, Transport Steel Products Such As Steel Structures, Steel Pipes, Steel Billets, Steel Ladles And Coils, Etc


    From One Locations To Another; Paper Roll Plants: Transfer Paper Coil Painting Shops: Transfer Work Piece Into The Painting Rooms Sand Blasting Rooms Other Industries: Shipbuilding, Quarries, Warehouses And Multi-Bay Workshops, Etc.

    Warehouses Q235 10T Electric Transfer Cart Material Handling

    3. Befanby Material Handling Equipment Introduce

    factory manufacturer flat cars custom manufacture flat carts high speed rail

    The transfer wagons factory manufacturer material handling equipment used in warehouses used to carry heavy objects in the workshop. Generally speaking, the driving behavior on the track is limited. In order to solve these problems, Xinxiang Hundred Percent Electrical And Mechanical Co., Ltd. has developed non-standard vehicles such as turntables, turning vehicles, and shuttle vehicles to assist in the use. Industrial rail flat cars are powered by KPX battery, KPD low-voltage rail power supply, KPJ cable reel power supply and KPC trolley line power supply; the track laying requirements of rail flat cars need to be appropriately based on power supply and factory conditions, such as low voltage Rail power supply requires insulation treatment; high temperature resistance treatment is required under high temperature conditions. In addition, the customization of industrial rail cars needs to be customized according to the specific needs of users, and the size of the design needs to be calculated by the technicians for the load.
    Warehouses Q235 10T Electric Transfer Cart Material Handling

    Welcome to inquiry us if you'd like to learn more

    4. Technique Parameter
    KPD series is a electric flat car factory manufacturer material handling equipment used in warehouses; KPX series is a battery electric motorized rail platform transfer trolley; KPJ series is a cable reel powered motorized rail trolley; KPT series is a tow cable powered electric rail trolley; KPC series is a safe sliding line Powered electric rail transfer trolley.
    ModelKPD-2tKPD-5tKPD-10tKPD-16tKPD-20tKPD-25tKPD-30tKPD-40tKPD-50tKPD-63t
    Rated load251016202530405063
    Table sizeLength(L)2000350036004000400045004500500055005600
    Width(W)1500200020002000220022002200250025002500
    Height(H)450450500500550600600650650750
    Wheel Base1200250026002800280032003200380042004300
    Rail Inner Gauage1200143514351435143514351435143514351435
    Wheel Diameter270300300350350400400500500600
    Wheel Quantity4444444444
    Ground Clearance50505050505050505075
    Running Speed0-250-250-250-200-200-200-200-200-200-20
    Motor Power11.21.622.233.5456.3
    Transformer Power3556.86.86.810101020
    Transformer Quatity1111111111
    Running Distance80808080808080605050
    Max Wheel Load14.425.842.664.577.794.5110.4142.8174221.4
    Reference Weight2.83.64.25.55.96.56.87.6810.8
    Recommended Rail ModelP15P18P18P24P24P38P38P43P43P50
