| Brand Name : | DIMA, TOYOTA |
| Model Number : | DMT5039XYCB1 |
| Certification : | CCC/ISO |
Land Cruiser Bulleproof Modification Use For Cash In Transit Vechicle
bulletproof armored Technical Data Sheet
| Product number | DMT503 9 XYC B1 |
| Chassis model | GTM64 90HSWN |
| Internal self-numbering | BBB1 |
| Drive form | 4 × 4 |
| Overall vehicle appearance ( length×width×height ) (mm) | 4855 ,4950 ×19 25 ×17 20 |
| Space size in the banknote transport compartment ( L×W×H ) (mm) | 765 × 1 265 × 960 |
| Volume (M3 ) | 1 |
| Whole vehicle curb weight (Kg) | 2215 |
| Maximum total mass (Kg) | 2640 |
| Maximum loading quality (Kg) | 1 0 0 |
| Number of crew ( people ) | 5 |
| Engine model and type | 2GR-FE six - cylinder EFI gasoline engine |
| Displacement (L) | 3456 |
| Emission Standards | GB18352.5-2013 National V |
| Maximum power (Kw/r/min) | 201/6200 |
| Maximum torque (Nm/r/min) | 337/4700 |
| Wheel torque ( front / rear ) (mm) | 16 3 5/16 30 |
| Wheelbase (mm) | 27 9 0 |
| Maximum speed (Km/h) | 1 75 |
| Tire specifications | 245/60 R18 |
| Protection level | A level |

DMT50 . 3 . 9 XYC Bl bulletproof cash transport car configuration table
| 2015 version configuration | Remarks | |
| Electric power steering | ● | |
| Remote central control door lock | ● | |
| Engine electronic anti-theft | ● | |
| Front and rear air conditioning system | ● | |
| 6- speed manual | ● | |
| Aluminum alloy wheels | ● | |
| Radial tire | ● | |
| CD supports MP3/WMA | ● | |
| Electric rearview mirror | ● | |
| ABS anti-lock brake system | ● | |
| Braking force distribution system (EBD/CBC ) | ● | |
| Brake assist system (EBA/BAS/BA ) | ● | |
| Traction Control System (ASR/TCS/TRC ) | ● | |
| Body stability control system (ESC/ESP/DSC) | ● | |
| Uphill assistance system | ● | |
| Driver's seat, passenger seat airbag | ● | |
| Front and rear center armrests | ● | |
| Rear seat front and rear adjustment | ● | |
| Adjustable rear backrest angle | ● | |
| Original car jack | ● | |
| Electronic monitoring system ( lifting screen, monitoring the rear of the car) | ▲ | |
| Sound and light alarm system for accidental opening of tailgate | ▲ | |
| Electric sunroof | ▲ | |
| Cockpit sides electric movable lift ticket transfer holes (holes and shooting) | ▲ | |
| Observation window of banknote compartment | ▲ | |
| Double mechanical lock/gear drive three-way lock mechanism | ▲ | |
| Two-way limit device for cash compartment door | ▲ | |
| Escort cabin ventilation channel | ▲ | |
| Rear tail valve exhaust pressure relief system | ▲ | |
| Flat steel plate of banknote compartment floor | ▲ | |
| Cockpit, escort cabin stepping mat | ▲ | |
| Powerful fire extinguisher | ▲ | |
| Shooting holes on both sides of the escort cabin | ★ | |
| Front and rear surround bumpers | ★ | |
| Police megaphone | ★ | |
| Circular warning lights | ★ | |
| DVR | ★ | |
| Speed limit alarm system | ★ | |
| Door switch warning system | ★ | |
| Leather seat cover | ★ | |
| Explosion-proof tires (bursting emergency safety device) | ★ | |
| Appearance logo pattern | ★ | |
● ——Chassis original configuration ▲ ——Add standard configuration ★——Optional configuration
Note: Because this model adopts a large-angle inclined structure of the front partition wall, the front sliding door of the cash compartment is not optional

|
