5year Warranty NJP Series Automatic Hard Gelatin Capsule Filling
Machine Auto Capsule Filler Machine For Powder
NJP-Series this model capsule filling machine is the latest D-type
innovative product developed by the company. It has 7 major
technological innovations and 2 invention patents.,It can fill
powder, granules and other materials into hollow capsules (000#,
00#, 0#, 1#, 2#, 3#, 4#, 5#). It can automatically finish the
production process including sowing, capsule separating, filling,
locking, unqualified capsule rejected and finished products output.
It has the advantages of accurate loading, stable operation and no
dust. It meets the GMP and JB20025-2004requirements,it is an ideal
equipment for filling medicines and health care product .
Service Commitment
Product Quality
All products are guaranteeded for one year, if any problems happen
in guarantee period.our company will maintain for free.
Spare Part Replacement
First mold for free,more than 50% discount if more order.
Technical Service
We can provide design, installation and debugging services or
remote maintanance teaching.
Delivery The Cargo To Nearest Port
We will arrange the shipment and delivery the cargo to your nearest
port,save time and cost.
Detail Product Information
Provide picture,video,instruction and product brochure.
Reply Timely
24 hours hot line ,we will reply email within 12 hours.
Technical Parameters
Machine Model | NJP-200 | NJP-400 |
Max. Output | 12000 Capsules/H | 24000 Capsules/H |
Capsule Size | Suitable for filling capsule size 00#-5# Supro/safefy capsule
size:A-E (need to exchange the spare parts/moulds accordingly) |
Dosage Type | Powder/Pellet/Tablet |
Power Supply | 380V 50HZ 3.7KW (Can be made according to the client`svoltage
standard) |
Noise Index | Less than 75dBA |
Machine Size/N.W. | 920mm x 800mm x 1900mm Net Weight: 950KG |
Packing Size/G.W. | 1600mm x 1000mm x 2150mm Gross Weight:1200KG |
Featurs
1.It has been improved the inner design turret, and imports beeline
bearings for each machine from Japan directly, so that it can be
sure a longer usage-life and precision of machine.
2. The working station cam runs under the good lubricating
condition, and maintains the inner lubrication of cam slot to a
full extent, increasing the pressure pulverization oil pump, thus
extends the operation life of the spare parts.
3. Single movement for both upper and lower segments with two-lip
seal provide a much better sealing performance.
4. It is controlled by the computer, has a stepless timing with the
frequency-conversion, the numberal showing makes an easy operation
and clear appearance.
5.The multi-bore dosing brings a precision dosage (it is controlled
around ±3.5%); The capsule qualified rate is higher than 99%. It
can be filled with the Chinese traditional medicine and the Western
medicine.
6. It has a protector equipment for the operator and the machine,
it has an automatic pause equipment when it is lack for the
material, It has steady and safe working, it is the best choice for
the hard capsule made factories
Machine Details
Adopts The Drawing Card Slot Design,With Reset SystemFilling
Rods.Convenient To Replace
Three-dimensional Adjustment,Easy Adjustment,HighPrecision Volume
Wide Range Of Materials Can Be Filled,Especially SuitableFor Highly
Viscous Materials
German Cai Si For 3 Seconds (zeiss) Optical Dividing Head,The
Filling Error ls Less Than 3%.
First: NBR Sealing Rubber,Prevents The Loss Of Lubricating Oil
Second: SIL Silicone Sealing Rubber,Prevents Powder Enters The
Bearing
Lines Of Aero Aliuminum Material With Dark BrownGlass,Insure The
Hvgiene And Hide The Process.
Real-time Counting,Print Production Date,Batch Number,Code,Etc.
Formed By CNC Machining Center Once,No Splicing;NoNoise In The
Production
Quantitative And Timely Refueling For Parts That NeedLubrication,No
Pollution
Modularized Setup,Convenient Inspection And Maintenance;With
Aviation Connector,More Safety
Applications
Pharmaceutical, medicine, and chemicals (powder, Pellet, granule,
pill),also can be used to fill vitamin, foodstuff and animal drug,
etc.
