    ASTM A210 Cold Drawn Superheater Seamless Boiler Tubes

    Ask Lasest Price
    Brand Name : HDT
    Model Number : Seamless Boiler Tubes
    Certification : ISO 9001 ISO14001
    Price : 800 - 9000 USD / ton
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : About 10000 ton / month
    Delivery Time : 20days
    • Product Details
    • Company Profile

    ASTM A210 Cold Drawn Superheater Seamless Boiler Tubes

    ASTM A 210 Cold Drawn Seamless Medium-Carbon Steel Boiler and Superheater Tubes


    QUALITY CONTROL from the raw material to finish products

    We can provide round bar/ billets MTC, and All Related Test Records during the production to the final products! Ensure all products are newly produced as per the contract.


    Up to 8,000 tons per month production capacity ensures FAST DELIVERY

    Four piercing machines, 20 sets of cold drawing bench, TWO 150mtr natural gas heat treatment furnaces, 12 tanks for Pickling / Washing / Phosphating, TWO Eddy Current and ONE Ultrasonic for NDT, Sophisticated Chemical and Mechanical test facilities, etc.


    C

    Mn

    P

    S

    Si

    Tensile Strength

    Yeild point

    Elongation

    0.06-0.18

    0.27-0.63

    0.035Max

    0.035Max

    0.25Max

    min ksi[Mpa] 47[325]

    min ksi[Mpa] 26[180]

    ≥35%


    Specification

    Cold Drawn Boiler Pipes
    Standard & Material
    ASTM A192/ASME SA192M
    ASTM A179/ASME SA179M
    ASTM A210/ASME SA210M: Grade: A1, C
    ASTM A213/ASME SA213M: Grade: T1, T2, T5, T9, T11, T12, T22, T23, T24, T91, T911, T92, T122
    GB5310-2013: Grade: 20G, 25MnG, 15MoG, 15CrMoG, 20MoG, 12CrMoG, 12Cr2MoG, 12Cr1MoVG, 12Cr2MoWVTiB, 10Cr9Mo1VNb, 15CrMoG, 10CrMo910
    DIN17175: ST35.8, ST45.8, 15Mo3, 13CrMo44, 10CrMo910, 14MoV63, 12Cr1MoV
    EN10216-1/2: Grade: P195GH, P235GH, P265GH, 13CrMo4-5, 10CrMo9-10, 16Mo3, 10CrMo5-5, X10CrMoVNb9-1
    BS 3059: 320, 360, 440, 620-460, 629-590, 762
    SizeO.D: 10-76mm
    Thickness: 0.8-12mm
    Length: 5.8mtr, 6mtr, 12 mtr or as per your requirement
    Surface TreatmentOiled, Varnished, Black Painted


    ASTM A210/A210M/ASME SA-210/SA-210M
    ASTM A 210 Cold Drawn Seamless Medium-Carbon Steel Boiler and Superheater Tubes

    Chemical Composition %
    GardeCSiMnPSCrNiCu
    A-1≤0.27≥0.100.29-1.06≤0.035≤0.035///
    C≤0.35≥0.10≤0.93≤0.035≤0.035///


    ASTM A 210 Cold Drawn Seamless Medium-Carbon Steel Boiler and Superheater Tubes Mechanical Property

    Mechanical Properties
    GradeYield Point
    (Mpa)
    Tensile Point
    (Mpa)
    Elongation
    (%)
    A-1≥255≥415≥30
    C≥275≥485

    ≥30


    Steel grade SA192 Chemical Composition & Mechanical properties

    Hardness

    Brinell Hardness

    Rockwell Hardness Number

    WT≥0.200in(5.1mm)

    WT<0.200in(5.1mm)

    137HRB

    77HRB


    QUALITY CONTROL
    1~ Incoming Raw Material Inspection
    2~ Raw Material Segregation to avoid steel grade mix-up
    3~ Heating and Hammering End for Cold Drawing
    4~ Cold Drawing and Cold Rolling, on line inspection
    5~ Heat Treatment, +A, +SRA, +LC, +N, Q+T
    6~ Straightening-Cutting to specified length-Finished Measuring Inspection
    7~ Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
    8~ Packing and Stocking.
