Auto Craft SS316 Juice Beverage Can Filling Machine
Automatic Beverage Juice Can Filling Sealing Machine
Our FY series easy-opening production line is specially designed
for filling non-carbonated beverages, such as fruit juice, tea
beverage, vegetable juice, etc. Just divide it into three pieces.
FY series easy-opening can filling machine is specially designed
and manufactured for filling non-carbonated beverages such as fruit
juice, tea beverage, vegetable juice, etc. into three-piece cans.
Specifications
Capacity: A-12000 bottles/hour ----48000 bottles/hour (500ml)
Applicable bottle type: 180ml-500ml
Applicable products: mineral water, juice
Refueling valve: According to customer needs, use mechanical valve.
Filling temperature: 85~88℃
Model | FY380 | FY1000 |
Production Capacity (C/M) | 300-350 | 800 |
Filling Valve | 36 | 60 |
Can Height | 52-300 | 45-200 |
Can Diameter | 53-110 | 49.5-65 |
Motor Power | Transmitted by capper | |
Weight | 2800 | 3550 |
Dimensions | 1720×1860×1900 | 2730×1905×1800 |
Model | FY6H | FY12H |
Production Capacity(C/M) | 300-350 | 800 |
Capping Head Number | 6 | 12 |
Can Height(mm) | 52-300 | 45-200 |
Can Diameter(mm) | 53-110 | 49.5-65 |
Motor Power | 7.5 | 22.5 |
Weight | 3000 | 3700 |
Dimensions | 2800×1000×2400 | 1450×1120×2180 |
Features
1. The outside surface of machine and all the parts in contact with
the filling material are made of superior stainless steel which not
only ensures beautiful machine appearance but also food safety and
hygiene
2. The filler is driven by capper which helps keep synchronization
between the filler and capper.
3. The can filling line is easier to assemble, dismantle and clean.
4. PLC control and frequency conversion are adopted for easy
operation and convenient adjustment.
Certificates
1. Our beverage machinery is approved as qualified products for
seven years by Chinese beverage industry association.
2. Our company is approved as excellent supplier of filling
equipment four times by Chinese beverage industry association.
3. Our company is entitled "Star Enterprise" by Chinese food and
packaging machinery industry association.
4. Our company is approved as the enterprise technical center of
Hebei Province.
5. Our company obtains ISO9001:2000 International Quality
Management System Certification.
6. Our company is awarded as demonstration enterprise of national
CAD application engineering by Ministry of Science and Technology
of China.
7. All our products are awarded as CE certification.
8. Our company becomes the vice chairman of Chinese food and
packaging machinery industry association.
FAQ
Q: What are the Primary Products of Your Company?
A: Our products mainly include water production line, juice
production line, tea production line, water filling machine, juice
filling machine, tea filling machine, and more.
Q: Where is Your Beverage Machinery Applied to?
A: Our beverage production lines are extensively used for packaging
of water, fruit juice, tea drinks, milk beverage, juice with
grains, sodas, protein beverages, energy drinks, and more.
Q: What are the Properties of Your Beverage Production Lines?
A: Our beverage machinery adopts automatic operation system which
greatly improves the performance and productivity of our packaging
machines. They have properties of multifunction, standard design,
modularization, digital control system, good compatibility, high
accuracy, flexibility, and high working efficiency.
All these measures together enable us to provide high quality
carbonated beverage production lines, can filling machines, juice
production lines, tea filling machines, etc, at competitive prices.
Q: Do Your Water Production Lines Meet Environmental Protection
Requirements?
A: Our water production lines are eco-friendly and energy-saving.
They adopt advanced environmental protection technologies from
Germany and Italy. All production procedures quite meet the
standards of ISO9001: 2000.
Q: Which Countries are Your Beverage Machinery Sold to?
A: Our products are widely exported to U.S.A, Russia, England,
Canada, Japan, Egypt, Mexico, South Africa, North Korea, Indonesia,
Mongolia, Malaysia, Dominica, Nigeria, Libya, Turkey, Kazakstan,
Iran, Yemen, Sudan, Vietnam, Bengal, Burma, Serbia, Macedonia,
Lebanon, Congo, Syria, Venezuela, Iraq, Saudi Arabia, and Kenya.
Q: What Kind of After-sale Services does Your Company Provide?
A: Installation guides, device debugging and technical trainings
are offered to our global customers to help them make full use of
our water production lines, tea filling machines, beverage
production lines, and other beverage machinery.
