    220HB CuW75 Copper Tungsten Edm Electrodes Spot Welding Electrodes

    Ask Lasest Price
    Brand Name : Sanhui
    Model Number : W80Cu20
    Certification : ISO9001:2008
    Price : USD 20-100 per PC
    Payment Terms : T/T, Western Union
    Supply Ability : 1000 pcs per month
    Delivery Time : about 15 days
    • Product Details
    • Company Profile

    220HB CuW75 Copper Tungsten Edm Electrodes Spot Welding Electrodes

    CNC 15.6g/cm3 Tungsten Copper Spot Welding Electrodes​


    Introduction of Tungsten Copper:

    Our tungsten copper alloy rods are processed by high purity of tungsten powder, copper powder and isostatic techniques. Tungsten copper alloy has features like high plasticity and high electrical and thermal conductivity and low thermal expansion. Both tungsten copper’ s electrical and thermal conductivity are good. Moreover, it owns low expansion and high temperature resistance.

    Chemical Composition of Tungsten Copper Alloy

    Code No.Chemical Composition %Mechanical properties
    CUImpurityWDensityRES( cm)
    (g/cm3 )HardnessConductivityTRS/ Mpa
    HBIACS/ %
    CuW(50)50+2.00.5Balance11.851153.254
    CuW(55)45+2.00.5Balance12.31253.549
    CuW(60)40+2.00.5Balance12.751403.747
    CuW(65)35+2.00.5Balance13.31553.944
    CuW(70)30+2.00.5Balance13.81754.142790
    CuW(75)25+2.00.5Balance14.51954.538885
    CuW(80)20+2.00.5Balance15.15220534980
    CuW(85)15+2.00.5Balance15.92405.7301080
    CuW(90)10+2.00.5Balance16.752606.5271160

    Specifications:

    1) Materials: W30Cu, W50Cu, 70%W/Cu, 75%W/Cu, 80%WCu, 90%WCu

    2) Density of tungsten copper:15.5~18.0g/cm3
    3) Technique: infiltering process
    4) Shape: Plate,sheet,strip,tube,rod,or machined parts
    5) Standard:ISO 9001:2008, ASTM B702


    Our strength:

    -High electrical conductivity bring very good erosion rate. Improve productivity.
    -High hardness maintains long life time.
    -High density characters present the lowest corner wear.
    -Dia. 1mm rod bend demo shows our super infiltration process control capability
