    2.5km/H Portable Pneumatic Mini Borewell Drilling Machine

    Ask Lasest Price
    Brand Name : ST
    Model Number : ST-180
    Certification : iso
    Payment Terms : T/T, L/C, Western Union, MoneyGram
    Supply Ability : 2000sets/month
    Delivery Time : 5days
    • Product Details
    • Company Profile

    2.5km/H Portable Pneumatic Mini Borewell Drilling Machine

    Water Drilling Rig Portable Pneumatic Mini Borewell Drilling Rigs Machine
    Pneumatic Borewell Machine
    Full hydraulic drilling rig mainly used to drilling wells,irrigation wells,ground source heating pump wells and boreholes for other purposes,especially for mountain and rock formation well projects.The rig can be drill in different layers.deep water well drilling rig uses full hydraulic control, and the top drive to drive the rotation of drilling tools with very high drilling efficiency.reasonable overall layout uses the tractor-mounted or full ground challis for transportation with good maneuverability.Very flexible in difficult roads and can be widely used in many fields such as resource exploration of hydrology wells, coal bed methane, the shallow layer of shale gas, terrestrial heat, etc, and can also be used for coal-mine gas exploitation salvage work.The top mounted driving head principal shaft has a great drift diameter, suitable for many kinds of construction work such as slurry drilling, air drilling, and air foam drilling, meeting the demands for well-drilling at different terrain strata.

    Pneumatic Borewell Machine Main Parameters

    Model
    ST180
    Drilling hole diameter
    140-254mm
    Drilling depth
    180m
    One-time advance length
    3.3m
    Walking speed
    2.5km/h
    Climbing angles (Max.)
    30
    Equipped capacitor
    55kw
    Using air pressure
    1.7-2.5mpa
    Air consumption
    17-31m³/min
    Drill pipe length
    1.5m, 2.0m, 3.0m
    Drill pipe diameter
    76mm, 89mm
    Rig lifting force
    12t
    Swing speed
    45-65rpm
    Swing torque
    3200-4600(N.m)
    Dimension
    3800*1500*2200mm
    Weight
    4500kg

    Feature:


    1.Safe and stable walking mechanism.
    2.The center of gravity is low and the ground clearance is large, so that it can cross the rough road easily. Special wheel motor drive has strong climbing ability and low failure rate.
    3.Advanced automatic leveling function of crawler and stop brake system not only make the drilling rig run stably, but also greatly reduce the impact of the ground on the drilling rig and ensure the driving safety.
    4. The unique anti stripping device has greatly improved the reliability of the drilling truck when walking.
    5.Vehicle-mounted diesel engine is adaptable to harsh environment. It can walk freely without external air compressor and is easy to move.

    Packaging:
    1)Wrapped by protective film;
    2)Packed by standard import & export wooden cases or carton boxes.
