    8mm 100kg/H Pulverizer Milling Machine With Dust Collection Device

    Ask Lasest Price
    Brand Name : BEISU
    Certification : ISO
    Supply Ability : 200 Set/Sets per Year for plastic pulverizer machine
    Price : $5,800.00
    • Product Details
    • Company Profile

    8mm 100kg/H Pulverizer Milling Machine With Dust Collection Device

    Application of Plastic PVC pulverizer milling machine with Dust collection device: The high-speed and high-efficiency pulverizer manufactured by Beisu Machinery is especially suitable for TPU, LLDPE, PVC, PE, PET, EVA, PP, PA, rubber, and various rigid, soft, elastomer, low-temperature materials, and film materials. , Sheet thermoplastic materials. According to the classification of the grinding materials, the mills are mainly divided into two categories: rotor (turbine) mills and disc mills.
    The working principle of the high-speed mill: The high-speed rotation of the grinding disc driven by the main shaft of the plastic pulverizer collides with the fixed cutter disc, cutting the material into powder (without sieve). The ground fine powder is brought into the vibrating screen along with the circulating air of the blower for sorting. The coarse material falls back to regrind, and the qualified fine powder enters the finished product storage with the cyclone and is discharged through the powder outlet pipe. That is the finished product. The air is discharged from the dust collector.

    Main features of PE LDPE LLDPE pulverizer(Disc type):

    A1.Low power consumption, high capacity

    A2.Simple structure and easy installation.

    A3.Host with the wind ,water circulation cooling system.

    A4.This Plastic pulverizer can deal with PE, LLDPE, LDPE, ABS, EVA, PET, PP etc.

    Model
    MP-400
    MP-500
    MP-600
    MP-800
    Diameter of milling chamber(mm)
    350
    500
    600
    800
    Motor power(kw)
    22-30
    37-45
    55
    75
    Cooling
    Water cooling + natural cooling
    Air Blower power(kw)
    3
    4
    5.5
    7.5
    Fineness of LDPE power
    30 to 100mm adjustable
    Output of pulverizer(kg/h)
    100-120
    150-200
    250-300
    400
    Dimension (mm)
    1800×1600×3800
    1900×1700×3900
    1900×1500×3000
    2300×1900×4100
    Weight (kg)
    1300
    1600
    1500
    3200

    Main features of PVC pulverizer(Rotor type):

    A1. The capacity of this model is higher than other kind of miller.

    A2. Equipped with dust collection device to reduce dust pollution.

    A3. Close blower for discharge can reduce labor intensity of worker and save money for clients.

    A4.The cover of main machine can be opened for maintain.

    A5.The cooling system include the water and wind cooling for the machine body
    Model
    SMF-400
    SMF-500
    SMF-600
    SMF-800
    Main Motor power (kw)
    30
    37
    45/55
    55/75
    Capacity (PVC 30-80 mesh)
    (kg/h)
    50-120
    150-200
    250-350
    300-500
    Material of conveying pipe
    Stainless steel
    Weight of PVC pulverizer
    (kg)
    1000
    1200
    1800
    2300
    Cooling
    Wind cooling +water cooling
