    EFW Carbon Steel Electric Fusion Welded Pipe ASTM A671 Gr CC60 Cl 32

    Ask Lasest Price
    Brand Name : DZSICO
    Model Number : ASTM A671
    Certification : ISO 9001:2008, SGS
    Price : $530.00 - $800.00 / Metric Ton
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1000 Ton / Tons Per Month ASTM A671 EFW Carbon Steel Pipes
    Delivery Time : 25 Days
    • Product Details
    • Company Profile

    EFW Carbon Steel Electric Fusion Welded Pipe ASTM A671 Gr CC60 Cl 32

    EFW Carbon Steel Electric Fusion Welded Pipe - ASTM A671 Gr CC60 Cl 32

    # ASTM A671 CC60 EFW Carbon Steel Pipe General Information

    ASTM A671 CC60 is a specification which covers standard requirements for electric fusion welded steel pipes. This ASTM A671 Gr CC60 Cl 22 S2 Pipe contains filler metal added to its alloy for welding purposes. As typical for the specified ASTM A671 Gr CC60 Cl 32 Pipe, the alloy has been designed for use in atmospheric as well as in low temperature settings. As mentioned by the specification, the a671 gr cc60 Carbon Steel pipe needs to be fabricated from a pressure vessel quality plate of several analysis and different strength levels as well. Several grades and classes of pipe for e.g. - ASTM A671 Grade CC60 Class 12 Pipes are to be provided. The grade mentioned on the ASTM A671 Grade CC60 Class 22 Pipe will designate the type of plate used in its manufacture. On the other hand, the class mentioned on it will designate the kind of heat treatment that has been performed during the manufacturing process of the ASTM A671 Gr CC60 Cl22 EFW Pipes.

    Apart from this the class mentioned on these pipes must be designated as to whether the welding conducted on the ASTM A671 CC60 Electric Fusion Welded Pipe is to be radiographically examined. The class also needs to be designated as to whether the ASTM A671 Grade CC60 Welded pipe has been pressure tested. Steel samples belonging to the ASTM A671 CC60 efw pipe are required to undergo a tension & transverse guided weld bend tests. The pipes must conform to the specified mechanical requirements. Generally, the carbon steel specified ASTM A671 CC60 can be used for various applications such as in chemical industries, power plants, and many other key industries. At Aesteiron, we offer several facilities to our clients purchasing the ASTM A671 Gr CC60 EFW Pipe such as delivery and packaging.


    # ASTM A671 CC60 EFW Carbon Steel Pipe Standard Stock Specifications

    ► ASTM A671 CC60 efw Pipe

    A671 gr cc60 Carbon Steel Pipe

    ASTM A671 Grade CC60 Class 22 Pipe

    ASTM A671 CC60 Electric Fusion Welded Pipe

    ASTM A671 Gr CC60 Cl 32 Pipe

    ASTM A671 Grade CC60 Class 12 Pipes


    Carbon Steel ASTM A671 Gr Cb60 Welded RectangularCarbon Steel A671 CC60 Cl22 Oil Pipeline
    A671 gr cc60 Carbon Steel Drill PipesASTM A671 Gr CC60 Cl22 Grooved Pipes
    ASTM A671 CC60 Square PipesASTM A671 Gr CC60 Cl 32 Hydraulic Pipes
    Large Diameter EFW ASTM A671 Gr CC60 Cl22 PipesSchedule 80 EFW ASTM A671 CC60 Pipes
    Schedule 40 Welded A671 cc60 cl22 PipesThin Wall A671 cc60 cl22 Pipes
    ASTM A671 CC60 Low Temp PipesEFW Black ASTM A671 Gr CC60 Cl 32 Pipes
    A671 cc60 cl22 Welded PipesASTM A671 Gr CC60 Class 22 Oval Pipes
    Carbon Steel ASTM A671 Gr Cb60 Erw PipesCarbon Steel A671 CC60 Cl22 Casing Pipes
    Epoxy Coated A671 gr cc60 Carbon Steel PipesCement lined ASTM A671 CC60 Pipes
    ASTM A671 Gr CC60 Cl22 Schedule 40 PipesASME B36.19 A671 gr cc60 Carbon Steel Pipes
    ASTM A671 Gr CC60 Cl 32 Schedule 10 PipesASTM A671 CC60 Double Wall Pipes
    ASTM A671 Gr CC60 Class 22 Efw PipesEpoxy lined A671 cc60 cl22 Pipes
    Carbon Steel A671 CC60 Cl22 Round PipesPTFE lined Carbon Steel A671 CC60 Cl22 Natural Gas Pipes
    A671 cc60 cl22 Rectangular PipesASTM A671 Gr CC60 Class 22 Hollow Pipes

    # ASTM A671 Gr CC60 Cl 32 Chemical Composition comparison with other classes

    A671 GradeChemical Properties
    CSiMnPSTi
    -/A45-/0.17-0.980.0350.035-
    -/A50-/0.22-
    CA55 / A550.28-
    -/B55-/0.200.13
    ~0.45
    CB60 / B600.24
    CB65 / B650.28
    CB70 / C700.311.30
    -/C55-/0.180.55
    ~0.98
    CC60/ C600.21
    CC65 / C650.240.79
    ~1.30
    CC70 / C700.27

    # ASTM A671 Gr CC60 Class 22 Pipe Mechanical Behaviour between relevant grades

    GradesYield Strength (N/mm2)Tensile Properties (N/mm2)Elongation (%)Welding point tensile strength (N/mm2)
    -/A45-/165-/310~450-/30-/310~450
    -/A50-/185-/345~485-/28-/345~485
    CA55 / A55205380~51527380~515
    -/B55-/205-/380~515-/27-/380~515
    CB60 / B60220415~55025415~550
    CB65 / B65240450~58523450~585
    CB70 / C70260485~62021485~620
    -/C55-/205-/380~515-/27-/380~515
    CC60/ C60220415~55025415~550
    CC65 / C65240450~58523450~585
    CC70 / C70260485~62021485~620

    1) Small diameter: Weight >Measurement
    a. Length: ≤5.8m, loaded in 20FT Container, Max 27-28tons
    b. Length: ≤11.8m, loaded in 40 FT Container, Max 27-28tons
    c. Length: ≥12m, shipped by bulk vessel. FILO terms


    2) Big dimater: Weight a. Size of

    20 FT Container(inside :5898*2352*2350mm)
    40 FT Container(inside :12024*2352*2395mm)


    FAQ

    1. How can I get a quotation from you ?

    You can leave us message, and we will reply every message in time. Or we may talk on line by Trademanager.
    And you can also find our contact information on contact page.


    2.Can I get samples before order ?
    Yes, of course. Usually our samples are free. we can produce by your samples or technical drawings. We can build the molds andfixtures.


    3. what is your delivery time ?
    The time of delivery is usually around 1 month(1*40FT as usual).
    We can send out in 2 days, if it has stock.


    4.What is your payment terms?
    Our usual payment term is 30% deposite, and rest against B/L. L/C is also acceptatble.EXW,FOB,CFR,CIF,DDU.


    5. How can you garantee what I got will be good ?
    We are factory with 100% predelivery inspection which garantee the quality.
    And as golden supplier on Alibaba. Alibaba assurance will make garantee,which means alibaba will pay your money back in advance if there is any problem with the products.


    6 How do you make our business long-term and good relationship?
    A:1. We keep good quality and competitive price to ensure our customers benefit ;
    2. We respect every customer as our friend and we sincerely do business and make friends with them,?
    no matter where they come from.
