    HAINA Full Servo 0.6Mpa 100T Adult Diaper Production Line

    Ask Lasest Price
    Brand Name : HAINA
    Model Number : HNJX-CK300
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 6 Sets per 1 Month
    Delivery Time : 180 work days
    • Product Details
    • Company Profile

    HAINA Full Servo 0.6Mpa 100T Adult Diaper Production Line

    Dual Drums High Performance Adult Diaper Making Machine


    Main Parameters


    Overall size38m×8m×4.5m(Including Mill, Pulp & Stacker)
    Design speed300PPM
    Stabe work speed250PPM
    Rejection rate≤4.0%(Excluding Glue, Splice, Raw Jointer Defectives)
    Effciency≥85%
    Power source380 /440V ,50/60Hz (3 Phases, 4 Lines, Ground-in)
    Machine capacity335KW(glue Machine & Air Compressor Not Included)
    Air pressure0.6-0.8Mpa
    Machine weight95-105Tons approxmatey

    Configuration&Options


    Product structureLeg cuff hydrophobic nonwoven.Top sheethydrophillc nonwoven.ADL,Cotton core(SAPmixed)Side tape,Waistband,Frontal tape,Back sheet
    Product sizeM:680*450(mm) L:800*650(mm) XL:950*760(mm)
    Program systemServo driven,intelligent HMI touch screen man-machine LCD interface.
    Tension systemTension control with buffer system,automatic web guiding system.to ensure materials stable working at ZERO speedsplice
    Driven systemServo drive.digital size chango.ensure run synchronously at full process.
    Safety systemSafety guard for operating side,emergency stop switch,security identifier,safety pull wire at driven side.
    Packaging systemAuto stacker to be defined by customor need (dual push dual exit),the stacking range:8-16pcs/pack adjustable.
    Web guiding systemGemany BST/USA FIFE
    Customized function available

    Customer Distribution


    At Present, Our Production Lines Are Used By Domestic High End Users, And Others Exported To South Asia, Southeast Asia, Middle East, South America, Africa And So On. Till Now, Total 120 Sets Of Our Machines Are Satisfied Using By Our Local And Overseas Customers. Now We Have Won Excellent Reputation In This Industry By Superb Professional Technology And Extremely High Level Of After-Sales Service.
