Weld Wire Mesh Panel 2.44m X 1.22m 8ft X 4ft - 1" Holes (12 Gauge)
Welded wire mesh panels are manufactured from high strength 2.5mm
thick (12 gauge) mild steel wire. The mesh is welded and galvanised
to protect the steel mesh sheets from rust and corrosion. The 8ft x
4ft weld mesh panels are one of the most popular galvanised flat
mesh sheets that we sell. With a square hole size of 25 x 25mm (1
inch x 1inch), the panels are rigid and suitable for security
fencing, machine guards in factories, garden fencing, aviaires,
bird cages, animal enclosures, gardening screening and for many
construction and building applications.
Welded Mesh Panel is made of superior quality welded mesh, with
flat even surface, firm structure, be used extensively in building,
food, agriculture and so on.
Assortments available:
Welded Stainless Steel Wire Mesh Panels
Galvanized Welded Mesh Panels
Hot-dip Zinc Plating Welded Mesh Panels
Property:
Welded wire mesh panels enjoy such properties as corrosion
resistance, aging resistance, sunshine resistance and weather
resistance.
Forms of corrosion resistance include electric galvanizing,
hot-dipp galvanizing, PVC spraying and PVC coating
welded mesh chain link fencing reinforcing mesh temporary fencing
welded mesh panel steel grating welded fencing
8ft x 4ft weld mesh panel uses
- Permanent outdoor use due to the hot-dipped galvanised protecive
coating
- Security mesh cages
- Machinery protection areas and factory "safe zones"
- Bird cages, aviaries and animal enclosures
- Dog fences
- Fox and Deer proof perimeter boundary fencing
- Ideal for protecting ponds from falling leaves and debris
- Construction applications
Galvanised mesh panels are supplied as rigid flat sheets and can be
cut to the size you require using heavy duty snips, a hack-saw or
angle grinder. Some edges to the panels may be sharp due to the
welded wires and the zinc galvanisation process. We stock a large
range of other sizes of steel mesh panels - heavier duty weld mesh
and larger aperture mesh.
Please note all sizes of panel, mesh aperture and wire gauge are
nominal and may vary slightly to what is stated due to
manufacturing tolerances.
| WIRE DIAMETER | OPENING |
| Inch | MM |
| 1.5mm | 1/2" X 1/2" | 12.7mm X 12.7mm |
| 2mm | 1" X 1" | 25.4mm X 25.4mm |
| 3mm | 1" X 1" | 25.4mm X 25.4mm |
| 3mm | 1-1/4" X 1-1/4" | 31.7mm X 31.7mm |
| 4mm | 1-1/2" X 1-1/2" | 38mm X 38mm |
| 4mm | 1-1/2" X 1-1/2" | 38mm X 38mm |
| 4mm | 1-1/2" X 1-1/2" | 38mm X 38mm |
| 2mm | 2" X 2" | 50.8mm X 50.8mm |
| 3mm | 2" X 2" | 50.8mm X 50.8mm |
| 3mm | 2" X 2" | 50.8mm X 50.8mm |
| 4mm | 2" X 2" | 50.8mm X 50.8mm |
| 4mm | 2" X 2" | 50.8mm X 50.8mm |
| 4mm | 2" X 2" | 50.8mm X 50.8mm |
| 4mm | 2" X 2" | 50.8mm X 50.8mm |
| 5mm | 2" X 2" | 50.8mm X 50.8mm |
| 5mm | 2" X 2" | 50.8mm X 50.8mm |
| 6mm | 4" X 2" | 101.6mm X 50.8mm |
| 6mm | 4" X 4" | 101.6mm X 101.6mm |
