    DC Type Enclosure Heat Exchanger


    200W/K DC Type Enclosure Heat Exchanger Industrial HEX For Telecom Outdoor Cabinet Door Mounted



    1. Technical Parameters

    Model No.HE06-200REH/01
    Environmental Performanceworking environmental temperature-20°C ~ 55°C
    storage working temperature-40°C ~ 70°C
    working humidity≤95%
    Thermal Performancerated heat exchange capacity200W/K
    rated heating capacity300/500W (optional)
    Electrical Performancerated input current3.5A
    rated input power168W
    rated input voltageDC48V
    Noise≤65dB


    2. Dimension: 455×200×820 mm (W×D×H)





    3. Introduction and Application Scope

    The HE06-200REH/01 Heat Exchanger is a full automation temperature control product. It uses intelligent controller to control the whole system of the heat exchanger. According to the variation of environment temperature, the intelligent controller can automatically detect, operate and record the whole system’s operating time, power consumption, event and historical data. It can store 100 event records and 1280 historical data records, and can enquire 256 days’ daily record information. The product is widely applied in telecom cabinet, small and medium sized telecom room, UPS room, outdoor base station room, outdoor advertising machine, bank ATM banknote exchange room etc.

    4. Features

    • Strong adaptability
    • High intelligence
    • High precision
    • High reliability
    • The heat exchange capacity can be set according to need
    • Low noise
    • Low energy consumption
    • With 4 way switching value detection
    • With 1 way room air conditioner control
    • Wide input voltage range: DC36 - 65V
    • With dry contact alarm output
    • Dust proof and water proof

    5. System Principle Diagram


    6. Electrical Wiring Diagram


    Wiring Ports:
    0V -48V: power supply input (voltage input: DC36 - 65V)
    A+ B- SGND: RS485 communication interface
    AL1 AL2: general alarm output
    F+ F- : auxiliary direct ventilation control output (output voltage: DC36V-65V)

    7. Product Picture




    8. Packing
