    LY-ADRP115-1700 Paper Coating Machine 380V 300m/min LDPE LLDPE

    Ask Lasest Price
    Brand Name : LAIYI
    Model Number : LY-ADRP115-1700
    Certification : CE , ISO9001
    Price : $90,000--$450,000/set
    Payment Terms : T/T,,L/C
    Supply Ability : 20sets/month
    Delivery Time : 5 months
    • Product Details
    • Company Profile

    LY-ADRP115-1700 Paper Coating Machine 380V 300m/min LDPE LLDPE

    LLDPE Non Woven Paper Plastic Coating Machine High Fastness Uniformity

    Double Side Extrusion Compound Laminating Paper Coating Machine

    This extrusion laminating machine uses resins such as LDPE, HDPE, PP, and EVA as raw materials. The process involves melting the plastic for extrusion through a T-die mold and laminating it with base materials. This machine is widely used for laminating substrates including paper, non-woven fabric, woven fabric, aluminum foil, and BOPP film. The finished product is known for its high fastness, uniform thickness, and excellent sealing capability.

    Main Technical Parameters
    MachineLY-ADRP-1200LY-ADRP-1400LY-ADRP-1700
    Machine width1200MM1400MM1700MM
    Effective widthMax 1100MMMax 1300mmMax 1600mm
    Machine Speed300mtr/min300mtr/min300mtr/min
    Screw diameterLD-115MMLD-115MMLD-115MM
    Extruder output400kg/h400kg/h400kg/h
    Used ResinsLDPE/LLDPE/PP/EVALDPE/LLDPE/PP/EVALDPE/LLDPE/PP/EVA
    Coating Thickness8-45um8-45um8-45um
    Rewinder/Unwinder DiaØ1200MMØ1200MMØ1200MM
    Base materialPaper(35-200g)Paper(35-200g)Paper(35-200g)
    • Two original paper rolls can be installed simultaneously on the shaftless unwinder
    • Auto-splicing controlled by computer without stopping the line
    • Web-guide device ensures uniform and neat paper/paper board passage
    • Bead cutter for edge trimming
    • Corona treatment on paper surface increases PE and paper peeling strength
    • Rewinder includes rewinding stand, tension control system, splicing device, and towing device
    • Tension control system ensures constant rewinding tension
    Laminating Equipment Specifications
    Form:Three Roll Lamination
    Chill roll diameterØ800mm
    Chill roll surface:Mirror and Matte
    Chill roll internal flow-path:Multi-head propeller
    Pressure roll diameter:Ø300mm
    Covered materials:Composite rubber
    Back roll diameter:Half mirror
    Back roll internal flow-path:Passageway filled with cooling water
    Speed reducer:Worm
    Composite driving motorInverter motor (11KW)
    Power supply:380V, 50HZ
    Double station unwinder of Paper Extrusion Laminating Machine
    Double Station Unwinder Features
    • Applies to multiple materials with wide range of uses
    • Automatically changes rolls without stopping machine or reducing speed
    • Features one-button and no-button type operation for simplicity and convenience
    • Compact design saves production space
    T-Die component of extrusion laminating machine Close-up of machine components

    "Professional qualifications to create brand" is Laiyi's business objective!

    "Create excellence by quality, provide service with honesty" is Laiyi's business purpose!
