Durable Aluminum Strip For Making Face Mask Nose Bridge
The alloy composition of 1060 aluminium is
Aluminium: 99.6% min
Copper: 0.05% max
Iron: 0.35% max
Magnesium: 0.03% max
Manganese: 0.03% max
Silicon: 0.25% max
Titanium: 0.03% max
Vanadium: 0.05% max
1060 aluminium alloy
1060 aluminium alloy is an aluminium based alloy in the
"commercially pure" wrought family (1000 or 1xxx series). It is
fundamentally very similar to 1050 aluminium alloy, with the
difference coming down to 0.1% aluminium by weight. However, while
both 1050 and 1060 are covered by the same ISO standard, they are
covered by different ASTM standards.
As a wrought alloy, it is typically formed by extrusion or rolling.
It is commonly used in the electrical and chemical industries, on
account of having high electrical conductivity, corrosion
resistance, and workability. It has low mechanical strength
compared to more significantly alloyed metals. It can be
strengthened by cold working, but not by heat treatment.
| Type | Aluminum Sheet/Foil/Strip |
| Grade & Temper | 1070/1060/1050/1350 O |
| Thickness | 0.2-2.0mm (other thickness can be produced) |
| Width | 20-1650mm |
| Inner Diameter | 150/300/400/500mm |
| Conductivity(%IACS) | ≥61.5 |
| Reisitivity number(Ω·mm2/m) | ≤0.02825 |
| Elongation(%) | >23 |
| Tensile Strength(Mpa) | >76 |
| Density in 20℃ | 2.7g/cm3 |
| Aluminum Alloy | 1070/1060/1050 O |
| Thickness(mm) | 0.2-0.3 | 0.4-0.8 | 1.0-2.0 | 2.0-3.0 |
| Tolerance(mm) | ±0.015 | ±0.02 | ±0.03 | ±0.06 |
| Width(mm) | 20-400 | 100-600 | 200-700 | 500-1600 |
| Width Tolerance(mm) | ±0.2 | ±0.3 | ±0.3 | ±1 |
Why Choose Aluminum to produce transformer?
1. Economic, means less cost for better achievements.
2. Conductivity of Copper is good, but Aluminum's is as double as
copper at the same price.
3. Aluminum is more flexible that means it easier to wind and place
in winding process.
4. Aluminum is lighter, easy to place.
In North America ,aluminum is the moost popular choice of winding
material for low-voltage, dry-type transformers.
We(Henan YOWO Industrial) have more than 10 years experiences of Aluminum sheet, Aluminum foil and Aluminum strip products. We
fully understand our customers' needs and requirements, and
strictly in accordance with international standards such as ASTM,
EN_AB, JIS, GB for the production of various grades of aluminum
products.
We make sure each piece of aluminum roll No Burrs, No Scratches of
Round Edge to fit for transformer winding.
Any size can be customized. No matter you need large quantity or
small quantity, or trial order, we'll all treat it seriously. Give
us one chance to be your reliable supplier in the near future!
