350mm Thickness S136H Plastic Injection Mold Tool Steel Block

350mm Thickness S136H Steel Block For Plastic Injection Mold

S136 Mold Steel

Takford special steel is one of the professional suppliers of S136 Mold Steel, We supply S136 Steel Round bar, Flat bar, Plates. S136 tool Steel China supplier and stockholders.We are the biggest the stockholders for S136 in China. Thickness from 8mm up to 500mm, wide max do 2200mm

Description

S136 Mold Steel material by electroslag melting smelting with good cast optical activity (mirror processing) good wear resistance and toughness at high temperature with good plasticity because of its high chromium content (13.6%) so its corrosion resistance is excellent, pre-add hard corrosion-resistant mirror mold steel S136 is a mirror rust-proof mold steel.

S136 mold steel with excellent corrosion resistance has been widely applied in the mold industry. However, in order to meet the increasing demands of injection products with complex structure and high quality, selective laser melting (SLM) as a novel manufacturing method is chosen due to its rapid fabricating parts with complex geometric shapes. Further, it is essential to enhance their hardness and wear property to prolong the service life of the injection mold.

Chemical Composition of S136 Mold Steel

S136 mold steel specification

S136 steel equivalent

Equivalent grades: 4CR13/HPM38/S-STAR/PAK90/2083/420/M300 Die Steel

Heat treatment

1.Annealing

In a protected state, heat up to 780 ℃ and then cool to 650 ℃ in the furnace at 10 ℃ per hour and then cool in the air.

2.Stress elimination

After roughing, must be heated to 650 ℃, both hot 2 hours, slowly cooling to 500 ℃, and then cooling in the air.

3.Hardened

Preheating Temperature: 600-850 ℃

Quenching temperature: 980-1050 ℃

Application

High degree of polishing and high requirements of the internal mold, corrosion-resistant plastic molds, production, medical, food industry, and other products. S136 can be used with all molds, due to their special nature, more suited to the needs of special environments.

DongGuan Misung mould Steel Co., Ltd is a leading company of supply plastic die steel, hot work steel, cold work steel, alloy structural steel, bearing steel, high speed tool steel, carbon steel, stainless steel and so on with different kinds of steel, we are begin to export the steel material from 2015 with fully export working experience to the market all over the world, such as Middle-East, Brazil, Poland, Turkey, Singapore, Malaysia, India, Italy, Korea and so on.

Misung mould Steel focuses on special steel industry over many years, we has established reliable and stable sourcing with over 40 mills and manufacturers in China, Our company have introduced large-sized Vertical saw machines, Horizontal saw machines, Milling machines, Grinding machines and other advance equipments, we can export our products by wholesales and retail sales, it can sale of whole plate or strip, all our products can meet the standards of DIN, AISI, JIS and GB, all the material should be inspected the ultrasonic, hardness and others strict inspection process before the shipment! We hope to cooperate with the customers from different countries, shares its experiences and develops with the world together.

Our company keeps the principle of "reputation is fisrt, customer is our god". We sincerely provide high quality, competitive price and quickly delivery to serve our valued customer, we desire to establish the mutual beneficial and long-term relation with importers from all over the world, please feel free to contact us and welcome you to visit our company!

Regular Stock:

S45C/S50C/1.2311/1.2312/P20/1.2738/718/1.2316/1.2083/S136/D2/D3/1.2080/1.2379/1.2510/1.2344/1.2714/H13/SKD11/SKD61/4140/5140 ETC. (Special steel will be ordered custom-made)
